Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Rim
Sizing
Recommended size guide.
XS
153cm - 162cm
SM
158cm - 169cm
MD
165cm - 174cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum
Suspension Fork
Advanced-Grade Composite, full-composite OverDrive steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Sora
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora 2x9
Cassette
Shimano CS-HG400, 9-speed, 11x34
Crank
Shimano Sora, 34/50 XS:165mm, S:170mm, M:170mm,
Bottom Bracket
Shimano cartridge
Chain
KMC X9
Pedals
N/A
Wheels
Front Hub
Giant S-R3 wheelset
Rear Hub
Giant S-R3 wheelset
Rims
Giant S-R3 wheelset
Spokes
Giant S-R3 wheelset
Tires
Giant S-R3 AC, 700x28c (30mm effective width)
Brakes
Brakes
Tektro TK-B177 calliper rim brake
Brake Levers
Shimano Sora
Cockpit
Stem
Liv Sport XS:80mm, S:90mm, M:100mm,
Handlebar
Liv Connect, 31.8mm, XS:38cm, S:40cm, M:40cm,
Grips
Liv
Seat
Saddle
Liv Approach
Seatpost
Giant D-Fuse, alloy 14mm offset XS:350mm, S:350mm, M:350mm,
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.48 mm | 1.51 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm |
| Front Center | 588 mm | 580 mm | 590 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 73 mm | 63.5 mm | 63.5 mm |
| Stack | 526 mm | 546 mm | 565 mm |
| Reach | 368 mm | 368 mm | 373 mm |
| Top Tube Length | 511 mm | 521 mm | 536 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 430 mm | 465 mm | 500 mm |
| Head Tube Angle | 70.5 ° | 72 ° | 72 ° |
| Head Tube Length | 135 mm | 150 mm | 170 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm |
| Wheelbase | 994 mm | 986 mm | 996 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 683 mm | 712 mm | 740 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 153 cm | 158 cm | 165 cm |
| Rider Max Height | 162 cm | 169 cm | 174 cm |
Model Overview
Avail 1 completes the Liv Avail model. 40 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Liv Avail 3 2022 is the cheapest bike model and costs 900$. Liv Avail 1 2022 is the most expensive one and costs 1215$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Endurance bikes average price
If you want to purchase a solid Endurance bike, it is important to know that the average cost is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Liv released this model in 2022, its price was 1215$. Doing a quick comparison, we notice that Avail 1 price is 93.09% smaller than the average cost of an Endurance bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on Avail 1 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 153 cm – 174 cm (5.02 ft – 5.71 ft). In short, you can easily find one that suits you.
