Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris, FSA -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminum
Suspension Fork
Aluminum, Alloy OverDrive steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Claris
Front Derailleur
Shimano Claris
Shift Levers
Shimano Claris
Cassette
Shimano HG50 11x34, 8-Speed
Crank
FSA Tempo, 34/50
Bottom Bracket
Sealed Cartridge, Threaded
Chain
KMC Z72
Pedals
Platform
Wheels
Front Hub
Giant Tracker Sport Road, [F] 24h, [R] 32h
Rear Hub
Giant Tracker Sport Road, [F] 24h, [R] 32h
Rims
Giant SR-3
Spokes
Stainless Steel, 14g
Tires
GIANT S-R4, 700x25
Brakes
Brakes
Tektro TK-R312
Brake Levers
Shimano Claris
Cockpit
Stem
Giant Sport
Handlebar
Giant Connect, 31.8mm
Seat
Saddle
Liv Contact Comfort
Seatpost
Giant Sport, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.48 mm | 1.51 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm |
| Front Center | 588 mm | 580 mm | 590 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 73 mm | 64 mm | 64 mm |
| Stack | 526 mm | 546 mm | 565 mm |
| Reach | 368 mm | 368 mm | 373 mm |
| Top Tube Length | 511 mm | 521 mm | 536 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 430 mm | 465 mm | 500 mm |
| Head Tube Angle | 70.5 ° | 72 ° | 72 ° |
| Head Tube Length | 135 mm | 150 mm | 170 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm |
| Wheelbase | 994 mm | 986 mm | 996 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 683 mm | 712 mm | 740 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
About this model
Avail 3 completes the Liv Avail model. Liv released 40 bikes variations of this model so far. You can easily view all of the Liv Avail bikes models from 2018, here.
Model range prices
Liv Avail 3 2018 is the cheapest bike model and costs 635$. Liv Avail SL 1 Disc 2018 is the most expensive one and costs 1430$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Endurance bikes average price
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Liv released this model in 2018, its price was 635$. Comparing this to the average Endurance bike price, we see that the price is 269.45% lower.
Overview of components
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
The wheels on Avail 3 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Avail 3 has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Liv Avail 3 bike has 3 sizes, in the range of 151 cm – 179 cm (4.95 ft – 5.87 ft). In conclusion, you won’t have a problem finding one that suits you.
