Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite
Suspension Fork
Advanced-grade composite, Hybrid OverDrive steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano 105
Cassette
Shimano Ultegra 11x34, 11-Speed
Crank
Shimano Ultegra, 34/50
Bottom Bracket
Shimano, Press Fit
Chain
KMC X11EL-1
Pedals
N/A
Wheels
Front Hub
Giant Performance Tracker Road Disc, Sealed Bearings, 12mm axles, 28h
Rear Hub
Giant Performance Tracker Road Disc, Sealed Bearings, 12mm axles, 28h
Rims
Giant PR-2 Disc, Tubeless
Spokes
Sapim Race 14/15g
Tires
Giant Gavia AC 1 Tubeless, 700x25, Folding
Brakes
Brakes
Giant Conduct, hydraulic disc, 140mm
Brake Levers
Shimano 105
Cockpit
Stem
Giant Connect
Handlebar
Giant Contact, 31.8mm
Seat
Saddle
Liv Contact Forward
Seatpost
Giant D-Fuse, composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.49 mm | 1.52 mm | 1.53 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 588 mm | 580 mm | 590 mm | 606 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 73 mm | 64 mm | 64 mm | 64 mm |
| Stack | 523 mm | 543 mm | 562 mm | 581 mm |
| Reach | 365 mm | 365 mm | 370 mm | 379 mm |
| Top Tube Length | 508 mm | 518 mm | 533 mm | 548 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 74 ° |
| Seat Tube Length | 410 mm | 445 mm | 480 mm | 515 mm |
| Head Tube Angle | 70.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 135 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 413 mm | 413 mm | 413 mm | 413 mm |
| Wheelbase | 991 mm | 983 mm | 993 mm | 1009 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 668 mm | 695 mm | 723 mm | 757 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
Avail Advanced 1 completes the Liv Avail Advanced model. Liv released 43 bikes variations of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Liv Avail Advanced 3 2018 is the cheapest bike model and costs 1685$. Liv Avail Advanced Pro 2018 is the most expensive one and costs 4800$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Endurance bikes
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Liv Avail Advanced 1 price was 2425$. Doing a quick comparison, we notice that Avail Advanced 1 price is 3.37% higher than the average cost of an Endurance bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the Avail Advanced 1 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Liv Avail Advanced 1 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, you can easily find one that suits you.
