Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris, FSA -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XXS
145cm - 156cm
XS
153cm - 162cm
SM
158cm - 169cm
MD
165cm - 174cm
LG
171cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum, disc
Suspension Fork
Advanced-Grade Composite, OverDrive, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Claris
Front Derailleur
Shimano Claris
Shift Levers
Shimano Claris
Cassette
Shimano HG50, 8-speed, 11x34
Crank
FSA Tempo, 34/50
Bottom Bracket
cartridge
Chain
KMC Z83
Pedals
N/A
Wheels
Front Hub
Giant S-R2 Disc wheelset, 12mm thru-axle
Rear Hub
Giant S-R2 Disc wheelset, 12mm thru-axle
Rims
Giant S-R2 Disc wheelset
Spokes
Stainless
Tires
Giant S-R3 AC, 700x32c, puncture protect
Brakes
Brakes
Tektro MD-C550 mechanical, 160mm
Brake Levers
Shimano Claris
Cockpit
Stem
Giant Sport
Handlebar
Giant Connect
Seat
Saddle
Liv Approach, UniClip accessory mount
Seatpost
Giant D-Fuse, alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.48 mm | 1.53 mm | 1.57 mm | 1.58 mm |
| Bottom Bracket Height | 256 mm | 256 mm | 256 mm | 256 mm | 256 mm |
| Front Center | 585 mm | 590 mm | 592 mm | 597 mm | 613 mm |
| Rake | 53 mm | 53 mm | 53 mm | 53 mm | 53 mm |
| Trail | 72.8 mm | 69.5 mm | 62.9 mm | 59.6 mm | 59.6 mm |
| Stack | 514 mm | 530 mm | 553 mm | 574 mm | 593 mm |
| Reach | 354 mm | 358 mm | 361 mm | 365 mm | 375 mm |
| Top Tube Length | 494 mm | 507 mm | 517 mm | 532 mm | 547 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74.5 ° | 74 ° | 74 ° |
| Seat Tube Length | 375 mm | 410 mm | 445 mm | 480 mm | 515 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 103 mm | 118 mm | 138 mm | 158 mm | 178 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 986 mm | 991 mm | 993 mm | 998 mm | 1014 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 645 mm | 673 mm | 701 mm | 728 mm | 758 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 145 cm | 153 cm | 158 cm | 165 cm | 171 cm |
| Rider Max Height | 156 cm | 162 cm | 169 cm | 174 cm | 182 cm |
About this model
Avail AR 4 belongs to the Liv Avail Ar model. 13 bikes variations carry this model name so far. You can easily view all of the Liv Avail Ar bikes models from 2021, here.
Model range prices
The most economical model, the Liv Avail AR 4 2021 has a starting price of 1000$. Liv Avail AR 1 2021 on the other hand is the most expensive at 1800$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Endurance bikes
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Liv Avail AR 4 price was 1000$. Comparing the average cost of an Endurance bike to this one, you will see that Avail AR 4 price is 134.6% lower.
Avail AR 4 components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The Avail AR 4 2021 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Avail AR 4 has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Avail AR 4 comes in 5 sizes, that range from 145 cm – 182 cm (4.76 ft – 5.97 ft). In conclusion, it won’t take much to find one that’s right for you.
