Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris, FSA -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XXS
145cm - 156cm
XS
153cm - 162cm
SM
158cm - 169cm
MD
165cm - 174cm
LG
171cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminum, 12x142mm thru-axle, disc
Suspension Fork
Advanced-grade composite, full-composite OverDrive steerer, 12x100mm, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Claris
Front Derailleur
Shimano Claris
Shift Levers
Shimano Claris
Cassette
Shimano CS-HG50, 8-speed, 11x34
Crank
FSA Tempo, 34/50 XXS: 165mm, XS: 165mm, S: 170mm, M: 170mm, L: 172.5mm
Bottom Bracket
cartridge
Chain
KMC Z83
Pedals
N/A
Wheels
Front Hub
Giant alloy, 12mm thru-axle
Rear Hub
Giant alloy, 12mm thru-axle
Rims
Giant S-R2 Disc wheelset
Spokes
stainless
Tires
Giant S-R3 AC, 700x32c
Brakes
Brakes
Tektro MD-C550 mechanical, Tektro rotors [F]160mm, [R]160mm
Brake Levers
Shimano Claris
Cockpit
Stem
Giant Sport XXS: 70mm, XS: 70mm, S: 80mm, M: 90mm, L: 90mm
Handlebar
Liv Connect, 31.8mm XXS: 380mm, XS: 380mm, S: 400mm, M: 400mm, L: 420mm
Grips
Liv All Condition
Seat
Saddle
Liv Approach
Seatpost
Giant Contact D-Fuse, alloy, 14mm offset XXS: 300mm, XS: 300mm, S: 300mm, M: 350mm, L: 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.442 mm | 1.47 mm | 1.52 mm | 1.56 mm | 1.569 mm |
| Bottom Bracket Height | 256 mm | 256 mm | 256 mm | 256 mm | 256 mm |
| Front Center | 585 mm | 590 mm | 592 mm | 597 mm | 613 mm |
| Rake | 53 mm | 53 mm | 53 mm | 53 mm | 53 mm |
| Trail | 72.8 mm | 69.5 mm | 62.9 mm | 59.6 mm | 59.6 mm |
| Stack | 522 mm | 538 mm | 561 mm | 582 mm | 601 mm |
| Reach | 362 mm | 366 mm | 369 mm | 373 mm | 383 mm |
| Top Tube Length | 502 mm | 515 mm | 525 mm | 540 mm | 555 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74.5 ° | 74 ° | 74 ° |
| Seat Tube Length | 375 mm | 410 mm | 445 mm | 480 mm | 515 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 103 mm | 118 mm | 138 mm | 158 mm | 178 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 994 mm | 999 mm | 1001 mm | 1006 mm | 1022 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 653 mm | 681 mm | 709 mm | 736 mm | 766 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 145 cm | 153 cm | 158 cm | 165 cm | 171 cm |
| Rider Max Height | 156 cm | 162 cm | 169 cm | 174 cm | 182 cm |
About this model
Avail AR 4 is part of the Liv Avail Ar model. There are 16 bikes that carry this model name. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Liv Avail AR 4 2024 is the cheapest bike model and costs 1011$. Liv Avail AR 1 2024 is the most expensive one and costs 1879$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Endurance bikes average price
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, this doesn’t mean that if you spend less money on an Endurance bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Liv released this model in 2024, its price was 1011$. Doing a quick comparison, we notice that Avail AR 4 price is 132.05% smaller than the average cost of an Endurance bike.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Liv Avail AR 4 2024, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Liv Avail AR 4 has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Liv Avail AR 4 bike has 5 sizes, in the range of 145 cm – 182 cm (4.76 ft – 5.97 ft). In conclusion, finding one for you shouldn’t be a problem.
