Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 650c / 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
XXS
145cm - 159cm
XS
157cm - 168cm
SM
165cm - 176cm
MD
174cm - 183cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite
Suspension Fork
Advanced-grade composite, Hybrid steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano 105
Shift Levers
Shimano BSR1 Bar End Shifters
Cassette
Shimano 105 11x28, 11-speed
Crank
Vision Trimax TT, 34/50
Bottom Bracket
FSA, Press Fit
Chain
KMC X11 EL
Pedals
N/A
Wheels
Front Hub
Giant Performance Tracker Road, Sealed bearing, [F] 16h [R] 24h
Rear Hub
Giant Performance Tracker Road, Sealed bearing, [F] 16h [R] 24h
Rims
Giant PA-2, Aero
Spokes
Sapim Race, 14/15g
Tires
Giant P-SL 2, 700x25, Front and Rear specific
Brakes
Brakes
Giant SpeedControl SL, w/ Ti hardware
Brake Levers
Tektro RX 4.1
Cockpit
Stem
Giant Connect
Handlebar
Giant Contact Alloy Base bar with Composite extensions, 31.8mm
Seat
Saddle
Liv Contact SL Forward, SST tubular rails
Seatpost
Avow, Composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD |
|---|---|---|---|---|
| Stack Reach Ratio | 1.17 mm | 1.27 mm | 1.27 mm | 1.28 mm |
| Front Center | 553 mm | 568 mm | 581 mm | 608 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 62 mm | 68 mm | 64 mm | 64 mm |
| Stack | 441 mm | 489 mm | 503 mm | 533 mm |
| Reach | 377 mm | 386 mm | 397 mm | 416 mm |
| Top Tube Length | 479 mm | 499 mm | 514 mm | 539 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 530 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 80 mm | 80 mm | 95 mm | 125 mm |
| Chainstay Length | 404 mm | 404 mm | 404 mm | 404 mm |
| Wheelbase | 948 mm | 960 mm | 973 mm | 1000 mm |
| Bottom Bracket Drop | 64 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 707 mm | 739 mm | 766 mm | 787 mm |
| Wheels | 650 | 700 | 700 | 700 |
| Rider Min Height | 145 cm | 157 cm | 165 cm | 174 cm |
| Rider Max Height | 159 cm | 168 cm | 176 cm | 183 cm |
About this model
Avow Advanced is a Liv Avow model. There are 21 bikes that carry this model name. You can easily view all of the Liv Avow bikes models from 2017, here.
Model range prices
Liv Avow Advanced 2017 is the cheapest bike model and costs 1850$. Liv Avow Advanced Pro 0 2017 is the most expensive one and costs 6700$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Triathlon bikes
According to our calculations, the average cost of a Triathlon bike that is reliable is 4177$. However, even if your budget is less than the average, you might still be able to get a top-quality Triathlon bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Liv Avow Advanced price was 1850$. If we compare this with the average Triathlon bike cost we notice that the price is 125.78% smaller.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the Avow Advanced model has aluminum wheels. These wheels are less popular than 650b and 700c. However, 650c wheels have better acceleration, and can climb easier than 700c.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Avow Advanced comes with Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Liv Avow Advanced bike has 4 sizes, in the range of 145 cm – 183 cm (4.76 ft – 6 ft). In short, it won’t be difficult to find the right one for you.
