Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite
Suspension Fork
Advanced-grade composite, Hybrid steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano 105
Shift Levers
Shimano BSR1 Bar End Shifters
Cassette
Shimano 105, 11x28, 11-Speed
Crank
FSA Trimax, 34/50
Bottom Bracket
FSA, Press fit
Chain
KMC X11EL-1
Pedals
N/A
Wheels
Front Hub
Giant Performance Tracker Road, Sealed Bearing, [F] 16h [R] 24h
Rear Hub
Giant Performance Tracker Road, Sealed Bearing, [F] 16h [R] 24h
Rims
Giant PA-2, Aero, Tubeless
Spokes
Dynamic Balanced Lacing, Sapim Race, 14/15g
Tires
Giant Race 1 Tubeless, 700x25, Folding
Brakes
Brakes
Giant SpeedControl
Brake Levers
Tektro RX 4.1
Cockpit
Stem
Giant Connect
Handlebar
Vision Trimax Base Bar with Liv Arm Pads and Extensions
Seat
Saddle
ISM Saddle
Seatpost
Avow composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.27 mm | 1.27 mm | 1.28 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm |
| Front Center | 568 mm | 581 mm | 608 mm |
| Rake | 40 mm | 40 mm | 40 mm |
| Trail | 68 mm | 64 mm | 64 mm |
| Stack | 485 mm | 499 mm | 529 mm |
| Reach | 382 mm | 393 mm | 412 mm |
| Top Tube Length | 495 mm | 510 mm | 535 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 480 mm | 510 mm | 530 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 80 mm | 95 mm | 125 mm |
| Chainstay Length | 400 mm | 400 mm | 400 mm |
| Wheelbase | 956 mm | 969 mm | 996 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm |
| Standover Height | 735 mm | 762 mm | 783 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
About this model
Avow Advanced completes the Liv Avow model. 21 bikes variations carry this model name so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Liv Avow Advanced 2018 is the cheapest bike model and costs 2040$. Liv Avow Advanced Pro 0 2018 is the most expensive one and costs 8160$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Triathlon bikes
If you want to purchase a solid Triathlon bike, it is important to know that the average cost is 4177$. However, this doesn’t mean that if you spend less money on a Triathlon bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Liv released this model in 2018, its price was 2040$. Comparing the average cost of a Triathlon bike to this one, you will see that Avow Advanced price is 104.75% lower.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When it comes to wheels, the Avow Advanced bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Avow Advanced has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 151 cm – 179 cm (4.95 ft – 5.87 ft). In conclusion, finding one for you shouldn’t be a problem.
