Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 400, Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminium, 12x142mm thru-axle, disc
Suspension Fork
Advanced-Grade Composite, full-composite OverDrive steerer, 12mm thru-axle, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano GRX RX-400
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano GRX RX-400, 2x10
Cassette
Shimano HG500, 11x34
Crank
FSA Omega Adventure, 32/48 XS:165mm, S:170mm, M:172.5mm
Bottom Bracket
FSA Mega EXA, press fit
Chain
KMC X10 with Missing Link
Pedals
N/A
Wheels
Front Hub
Giant S-X2 Disc wheelset
Rear Hub
Giant S-X2 Disc wheelset
Rims
Giant S-X2 Disc wheelset
Spokes
Giant S-X2 Disc wheelset
Tires
Giant CrossCut AT 2, 700x38c, tubeless
Brakes
Brakes
Shimano GRX RX-400 hydraulic, Giant MPH rotors [F]160mm, [R]160mm
Brake Levers
Shimano GRX RX-400 hydraulic
Cockpit
Stem
Giant Contact XS:70mm, S:80mm, M:90mm
Handlebar
Giant Contact XR D-Fuse, 31.8
Grips
Liv All Condition
Seat
Saddle
Liv Approach
Seatpost
Giant D-Fuse, alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.48 mm | 1.57 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm |
| Front Center | 596 mm | 603 mm | 605 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 75.9 mm | 75.9 mm | 72.5 mm |
| Stack | 537 mm | 565 mm | 595 mm |
| Reach | 385 mm | 383 mm | 379 mm |
| Top Tube Length | 522 mm | 532 mm | 542 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° |
| Seat Tube Length | 390 mm | 420 mm | 465 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° |
| Head Tube Length | 95 mm | 125 mm | 155 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1020 mm | 1027 mm | 1029 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm |
| Standover Height | 685 mm | 713 mm | 751 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
About this model
Devote 1 belongs to the Liv Devote model. 22 bikes variations carry this model name so far. You can easily view all of the Liv Devote bikes models from 2022, here.
Model range prices
Liv Devote 2 2022 is the most economical model, with a starting price of 1082$. Liv Devote Advanced Pro 2022 on the other hand costs 4266$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Liv Devote 1 price was 1400$. Comparing this to the average Gravel bike price, we see that the price is 75.86% smaller.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The Devote 1 2022 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Devote 1 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Devote 1 comes in 3 sizes, that range from 151 cm – 179 cm (4.95 ft – 5.87 ft). In conclusion, it won’t take much to find one that’s right for you.
