Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox Recon Silver RL
-
Groupset Deore, Alivio -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum
Suspension Fork
RockShox Recon RL Solo Air, 120mm travel, Boost QR15x110mm, tapered steerer
Rear Shock
RS Monarch R
Drivetrain
Rear Derailleur
Shimano Deore, Shadow+
Front Derailleur
Shimano Alivio
Shift Levers
Shimano Deore, 2x10
Cassette
Shimano Deore, 11x42
Crank
Praxis custom Cadet 2x10 Boost, 26x36
Bottom Bracket
Praxis 90 Press Fit
Chain
KMC X10-1
Pedals
N/A
Wheels
Front Hub
Giant Tracker Sport, 28H, [F] Boost QR15x110mm, Performance Tracker, sealed bearing [R] Giant Tracker Sport QR5x141, 4 bearing
Rear Hub
Giant Tracker Sport, 28H, [F] Boost QR15x110mm, Performance Tracker, sealed bearing [R] Giant Tracker Sport QR5x141, 4 bearing
Rims
Giant AM 27.5 tubeless ready sleeve-joint rim, 30mm inner width
Spokes
Sapim
Tires
Maxxis Ardent 27.5x2.4, 60tpi EXO, tubeless
Brakes
Brakes
Shimano MT201 [F] 180mm [R] 160mm
Brake Levers
Shimano MT201
Cockpit
Stem
Giant Connect, ±8-degree
Handlebar
Giant Connect Trail
Seat
Saddle
Liv Contact (forward)
Seatpost
Giant Contact Switch dropper post with remote lever, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.35 mm | 1.34 mm | 1.32 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 675 mm | 691 mm | 707 mm | 723 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 104 mm | 104 mm | 104 mm | 104 mm |
| Stack | 557 mm | 562 mm | 571 mm | 580 mm |
| Reach | 401 mm | 415 mm | 427 mm | 439 mm |
| Top Tube Length | 562 mm | 577 mm | 592 mm | 607 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 406 mm | 445 mm | 490 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1106 mm | 1122 mm | 1138 mm | 1154 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 687 mm | 702 mm | 730 mm | 756 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
Embolden 1 is a Liv Embolden model. There are 14 bikes that carry this model name. Take a sneak peek at all Liv Embolden bikes models from 2019, by clicking here.
Model range prices
Liv Embolden 2 2019 is the cheapest bike model and costs 1550$. Liv Embolden 1 2019 is the most expensive one and costs 1750$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1750$. Comparing the average cost of a Trail bike to this one, you will see that Embolden 1 price is 57.83% smaller.
Embolden 1 components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The Embolden 1 2019 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Embolden 1 comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the Embolden 1. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
