Liv Embolden E+, 2 – 625 2022
2022 E-bike
Estimate price |
4,587$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Suntour XCR Air
-
Groupset Deore -
Suspension Full -
Motor Yamaha 250W 70Nm mid-drive -
Battery EnergyPak Smart 625Wh 36V Integrated Lithium-Ion -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 163cm
SM
158cm - 169cm
MD
164cm - 175cm
LG
170cm - 181cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX Aluminum, 120mm FlexPoint suspension system, 141mm Boost QR, Integrated KS18 Kickstand Mount
Suspension Fork
SR Suntour XCR 34 Air LO-R, 130mm travel, tapered steerer, Lockout, 110x15 thru-axle
Rear Shock
RockShox Monarch R, High Volume, 184x44mm, custom tuned
Drivetrain
Rear Derailleur
Shimano Deore, 10-Speed, Shadow+ LinkGlide
Shift Levers
Shimano Deore LinkGlide
Cassette
Shimano CS-M5130, 11-48T, 10-speed LinkGlide
Crank
Forged Alloy minimal Q-factor, 36T Steel Direct Mount ring (XS/S:160, M/L:165)
Bottom Bracket
-
Chain
Shimano, CN-LG500, 9/10/11speed for LinkGlide
Pedals
Aluminum Platform
Wheels
Front Hub
Giant eTracker Sport, [F] 15mm Thru-Axle [R] 141mm QR
Rear Hub
Giant eTracker Sport, [F] 15mm Thru-Axle [R] 141mm QR
Rims
Giant AM 27.5" / 29", Tubeless ready, 30mm inner width (XS: 27.5+ / S-L: 29)
Spokes
Stainless Steel
Tires
Maxxis Rekon 29x2.4"/ 27.5x2.4" foldable, 60tpi, EXO, Tubeless Ready (XS: 27.5, S-L: 29)
Brakes
Brakes
Tektro HD-M745 Orion, 4-piston, hydraulic disc, 203mm
Brake Levers
Tektro HD-M745 Orion
Cockpit
Stem
Giant Contact
Handlebar
Giant Connect TR Riser 31.8x750~780mm (XS-S: 750 / M-L: 780)
Grips
Liv Contact Microtech Plus, Lock-on
Seat
Saddle
Liv Sylvia E+
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Motor & Battery
Motor
SyncDrive Sport, 70Nm, Powered by Yamaha
Battery
EnergyPak Smart 625Wh 36V Integrated Lithium-Ion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.45 mm | 1.43 mm | 1.41 mm |
| Bottom Bracket Height | 335 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 683 mm | 698 mm | 714 mm | 730 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 103.5 mm | 103.5 mm | 103.5 mm | 103.5 mm |
| Stack | 591 mm | 591 mm | 600 mm | 609 mm |
| Reach | 392 mm | 407 mm | 419 mm | 431 mm |
| Top Tube Length | 562 mm | 577 mm | 592 mm | 607 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 406 mm | 445 mm | 490 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 472 mm | 472 mm | 472 mm | 472 mm |
| Wheelbase | 1154 mm | 1169 mm | 1185 mm | 1201 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 707 mm | 735 mm | 762 mm | 783 mm |
| Wheels | 27" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 158 cm | 164 cm | 170 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm |
Model Overview
Embolden E+, 2 – 625 belongs to the Liv E Embolden model. There are 21 e-bikes that carry this model name. You can easily view all of the Liv E Embolden e-bikes models from 2022, here.
Model range prices
Liv Embolden E+ 2 2022 is the most affordable e-bike of this model and has a price of 3629$. On the other hand, Liv Embolden E+ 1 2022, is the most expensive and costs 4883$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail e-bikes average price
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4246$. Comparing this to the average Trail e-bike price, we see that the price is 26.18% more expensive.
Overview of components
Fork
Liv Embolden E+, 2 – 625 2022 e-bike is equipped with the Suntour XCR Air fork, and has 130mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this e-bike has the RockShox Monarch R model, with a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The Embolden E+, 2 – 625 2022 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Liv Embolden E+, 2 – 625 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 152 cm – 181 cm (4.99 ft – 5.94 ft). In conclusion, it won’t take much to find one that’s right for you.
