Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 160mm -
Fork RockShox
-
Groupset X1, GX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, Advanced Forged composite upper rocker, 160mm Maestro suspension
Suspension Fork
RockShox Lyric RC Dual Position, Maxle Stealth, Boost, OverDrive, 130-160mm travel
Rear Shock
RockShox Deluxe R, Trunnion mount
Drivetrain
Rear Derailleur
SRAM X1
Front Derailleur
N/A
Shift Levers
SRAM GX
Cassette
SRAM XG-1180 10x42, 11-speed
Crank
SRAM X1, 30T, w/ MRP AMG V2 Guide (Alloy backplate)
Bottom Bracket
SRAM GXP, Press fit
Chain
KMC X11 EL
Pedals
N/A
Wheels
Front Hub
Giant Performance Tracker Disc, 28h, [F] Boost 110x15mm, [R] Boost 148x12mm
Rear Hub
Giant Performance Tracker Disc, 28h, [F] Boost 110x15mm, [R] Boost 148x12mm
Rims
Giant P-AM2
Spokes
Sapim Race, 14/15g
Tires
[F] Schwalbe Magic Mary, 27.5x2.35, Snakeskin, TL Easy, Trail Star [R] Schwalbe Hans Dampf, 27.5x2.35, Snakeskin, TL Easy, Pace Star
Brakes
Brakes
SRAM Guide RS, hydraulic disc, [F] 200m [R] 180mm
Brake Levers
SRAM Guide RS
Cockpit
Stem
Truvativ Holzfeller
Handlebar
Giant Contact SL DH, 31.8mm
Seat
Saddle
Liv Contact Upright
Seatpost
Giant Contact SL Switch Trail, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.39 mm | 1.35 mm | 1.35 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Front Center | 710 mm | 725 mm | 753 mm | 770 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 109 mm | 109 mm | 109 mm | 109 mm |
| Stack | 575 mm | 579 mm | 593 mm | 607 mm |
| Reach | 403 mm | 417 mm | 438 mm | 449 mm |
| Top Tube Length | 569 mm | 584 mm | 609 mm | 624 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 365 mm | 380 mm | 431 mm | 482 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 95 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1144 mm | 1159 mm | 1187 mm | 1204 mm |
| Bottom Bracket Drop | 5 mm | 5 mm | 5 mm | 5 mm |
| Standover Height | 709 mm | 716 mm | 754 mm | 794 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
Hail 1 belongs to the Liv Hail model. 12 bikes variations carry this model name so far. You can easily view all of the Liv Hail bikes models from 2017, here.
Model range prices
Liv Hail 2 2017 is the cheapest bike model and costs 3250$. Liv Hail Advanced 0 2017 is the most expensive one and costs 8250$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro bikes
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2017 for 4200$. Doing a quick comparison, we notice that Hail 1 price is 16.7% more expensive than the average cost of an Enduro bike.
Hail 1 components
Fork
The fork installed on this bike is the RockShox model. The travel on this model is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The Hail 1 has a rear shock with a travel of 160mm. The model RockShox Deluxe R is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The wheels on Hail 1 are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Liv Hail 1 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Liv Hail 1 bike has 4 sizes, in the range of 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, finding one for you shouldn’t be a problem.
