Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Fork Fox
-
Groupset X0, X9 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, 5.5" Maestro suspension
Suspension Fork
Fox Float CTD Talas Performance w/ 15mm thru-axle, OverDrive steerer, 120-140mm travel
Rear Shock
Fox Float CTD
Drivetrain
Rear Derailleur
SRAM X0, Type 2
Front Derailleur
SRAM X9
Shift Levers
SRAM X0 Trigger
Cassette
SRAM PG1050 11x36, 10-speed
Crank
SRAM S1000, 22/36
Bottom Bracket
SRAM, Press fit
Chain
KMC X10
Pedals
N/A
Wheels
Front Hub
Giant P-TRX1 WheelSystem; 28h, [F] 15mm axle, [R] 142x12 axle
Rear Hub
Giant P-TRX1 WheelSystem; 28h, [F] 15mm axle, [R] 142x12 axle
Rims
Giant P-TRX1 Composite WheelSystem; 27mm wide, Tubeless compatible
Spokes
Sapim Race, 14/15g
Tires
Schwalbe Nobby Nic, Snake skin, 27.5x2.25
Brakes
Brakes
Avid Guide R, Hydraulic disc, 160mm
Brake Levers
Avid Guide R
Cockpit
Stem
Giant Contact SL
Handlebar
Giant Contact SL, Low rise, 31.8mm
Seat
Saddle
Fi'zi:k Donna, MG rails
Seatpost
Giant Contact SL Switch-R, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.591 mm | 1.526 mm | 1.484 mm | 1.483 mm |
| Stack | 584 mm | 589 mm | 598 mm | 608 mm |
| Reach | 367 mm | 386 mm | 403 mm | 410 mm |
| Top Tube Length | 541 mm | 559 mm | 579 mm | 589 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 99 mm | 104 mm | 114 mm | 124 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1087 mm | 1107 mm | 1128 mm | 1140 mm |
| Standover Height | 686 mm | 691 mm | 716 mm | 754 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
Intrigue 1 completes the Liv Intrigue model. Liv released 36 bikes variations of this model so far. Check out the entire range from 2015 of this model, by clicking this link.
Model range prices
Liv Intrigue 2 2015 is the most affordable bike of this model and has a price of 2825$. On the other hand, Liv Intrigue 1 2015, is the most expensive and costs 4700$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4700$. Comparing this to the average Trail bike price, we see that the price is 70.17% higher.
Intrigue 1 components
Fork
This bike has the Fox fork installed. The fork’s travel is 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
From the factory, it comes with the Fox Float CTD rear shock model, which has a travel of 140mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The Intrigue 1 2015 bike is equipped with 27.5″ carbon wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, it won’t take much to find one that’s right for you.
