Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 140mm -
Fork RockShox Pike RCT3
-
Groupset X1 -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, 5.5" Maestro suspension
Suspension Fork
RockShox Pike RCT3 Solo Air w/ Maxle Stealth thru-axle, OverDrive steerer, 160mm travel
Rear Shock
RockShox Monarch Plus DebonAir RT
Drivetrain
Rear Derailleur
SRAM X1, Type 2
Front Derailleur
N/A
Shift Levers
SRAM X1, Rear only
Cassette
SRAM XG-1180 10x42, 11-speed
Crank
SRAM X1, 30T
Bottom Bracket
SRAM, Press Fit
Chain
KMC X11L
Pedals
N/A
Wheels
Front Hub
Giant Performance Tracker Disc, 32h, [F] 15mm axle, [R] 142x12mm axle
Rear Hub
Giant Performance Tracker Disc, 32h, [F] 15mm axle, [R] 142x12mm axle
Rims
Giant P-AM2, Double wall
Spokes
Stainless Steel, 14/15g
Tires
[F] Schwalbe Hans Dampf, 27.5x2.35, Snakeskin, Trailstar [R] Schwalbe Rock Razor, 27.5x2.35, Snakeskin, Pacestar
Brakes
Brakes
SRAM Guide RS, Hydraulic disc, [F] 170mm [R] 160mm
Brake Levers
SRAM Guide RS, Hydraulic disc
Cockpit
Stem
Giant Contact SL AM
Handlebar
Contact SL Trail, Mid rise, 31.8mm
Seat
Saddle
Liv Contact SL forward, SST tubular metalic rails
Seatpost
Giant Contact SL Switch, dropper, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.653 mm | 1.587 mm | 1.541 mm |
| Stack | 590 mm | 595 mm | 604 mm |
| Reach | 357 mm | 375 mm | 392 mm |
| Top Tube Length | 541 mm | 559 mm | 579 mm |
| Seat Tube Angle | 72.8 ° | 72.8 ° | 72.8 ° |
| Head Tube Angle | 66.9 ° | 66.9 ° | 66.9 ° |
| Head Tube Length | 99 mm | 104 mm | 114 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1095 mm | 1115 mm | 1138 mm |
| Standover Height | 696 mm | 699 mm | 726 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
About this model
Intrigue SX belongs to the Liv Intrigue model. There are 36 bikes that carry this model name. Check out the entire range from 2016 of this model, by clicking this link.
Model range prices
The most economical model, the Liv Intrigue 1 2016 has a starting price of 3200$. Liv Intrigue SX 2016 on the other hand is the most expensive at 4475$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Liv Intrigue SX price was 4475$. Comparing this to the average Trail bike price, we see that the price is 62.02% higher.
Overview of components
Fork
Liv Intrigue SX 2016 bike is equipped with the RockShox Pike RCT3 fork, and has 160mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Liv Intrigue SX bike has the RockShox Monarch Plus DebonAir RT model installed, and has a travel of 140mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The Intrigue SX 2016 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Liv Intrigue SX is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 151 cm – 179 cm (4.95 ft – 5.87 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
The Liv model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
