Liv Intrigue X E+ 2, Pro 2022
2022 E-bike
Estimate price |
6,000$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 140mm -
Fork Fox Rhythm Float 36
-
Groupset XT, SLX -
Suspension Full -
Motor Yamaha 250W 80Nm mid-drive -
Battery EnergyPak Smart 625Wh EnergyPak Plus range extender compatible -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS High
152cm - 163cm
XS Low
152cm - 163cm
SM High
158cm - 169cm
SM Low
158cm - 169cm
MD High
164cm - 175cm
MD Low
164cm - 175cm
LG High
170cm - 181cm
LG Low
170cm - 181cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminum, Advanced Forged Composite Upper Rocker, 140mm Maestro Suspension System, 'Boost' 148x12QR, ISS
Suspension Fork
Fox 36 Float Rhythm, 150mm travel, 44mm offset, EVOL, Grip Damper, Sweep adjust, Boost 110x15QR, e-optimized
Rear Shock
Fox Float DPS Performance, EVOL Large Volume sleeve, 3-position Lever, 185x52.5mm Trunnion mount, custom tuned
Drivetrain
Rear Derailleur
Shimano Deore XT, 12-speed, Shadow+
Front Derailleur
MRP 1X CS custom
Shift Levers
Shimano SLX
Cassette
Shimano CS-M6100-12, 10-51T, 12-speed
Crank
Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (XS/S:160, M:165, L:170)
Bottom Bracket
-
Chain
KMC e.12 Turbo, EcoProteq, e-bike optimized
Pedals
Flatpedal
Wheels
Front Hub
Shimano Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spling Drive Body Thru-axle
Rear Hub
Shimano Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spling Drive Body Thru-axle
Rims
Giant AM 29 / 27.5+, Tubeless ready, 30mm inner width
Spokes
Sapim E-Lite [r] Race [f]
Tires
Maxxis Assegai 29x2.6" foldable, Tubeless, EXO [F] Maxxis Dissector 29x2.6" Foldable, Tubeless, EXO+ [R] (XS: 27.5+ / S-L: 29)
Brakes
Brakes
Shimano Deore BR-M6120, 4-piston, hydraulic disc, 203mm
Brake Levers
Shimano Deore BL-M6100, I-spec EV
Cockpit
Stem
Giant Contact SL 35
Handlebar
Giant Contact 35 Trail, 35x760~780mm (XS-S: 760 / M-L: 780)
Grips
Liv Supera Lock-on
Seat
Saddle
Liv Sylvia E+
Seatpost
Giant Contact Switch, dropper, 30,9mm (XS-S: 100, M:125, L:150)
Motor & Battery
Motor
SyncDrive Pro,80Nm, Powered by YAMAHA
Battery
EnergyPak Smart 625Wh EnergyPak Plus range extender compatible
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS High | XS Low | SM High | SM Low | MD High | MD Low | LG High | LG Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.45 mm | 1.41 mm | 1.46 mm | 1.37 mm | 1.42 mm | 1.34 mm | 1.38 mm |
| Bottom Bracket Height | 354 mm | 344 mm | 354 mm | 344 mm | 354 mm | 344 mm | 354 mm | 344 mm |
| Front Center | 721 mm | 718 mm | 727 mm | 725 mm | 745 mm | 743 mm | 767 mm | 765 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 124.2 mm | 129.6 mm | 118.1 mm | 123.4 mm | 118.1 mm | 123.4 mm | 118.1 mm | 123.4 mm |
| Stack | 581 mm | 587 mm | 604 mm | 610 mm | 609 mm | 615 mm | 618 mm | 624 mm |
| Reach | 414 mm | 405 mm | 428 mm | 418 mm | 444 mm | 434 mm | 461 mm | 452 mm |
| Top Tube Length | 567 mm | 567 mm | 570 mm | 570 mm | 587 mm | 587 mm | 607 mm | 607 mm |
| Seat Tube Angle | 75.2 ° | 74.5 ° | 76.7 ° | 76 ° | 76.7 ° | 76 ° | 76.7 ° | 76 ° |
| Seat Tube Length | 385 mm | 385 mm | 405 mm | 405 mm | 435 mm | 435 mm | 460 mm | 460 mm |
| Head Tube Angle | 65.7 ° | 65 ° | 66.5 ° | 65.8 ° | 66.5 ° | 65.8 ° | 66.5 ° | 65.8 ° |
| Head Tube Length | 95 mm | 95 mm | 95 mm | 95 mm | 100 mm | 100 mm | 110 mm | 110 mm |
| Chainstay Length | 474 mm | 474 mm | 474 mm | 474 mm | 474 mm | 474 mm | 474 mm | 474 mm |
| Wheelbase | 1195 mm | 1192 mm | 1200 mm | 1197 mm | 1218 mm | 1215 mm | 1240 mm | 1237 mm |
| Bottom Bracket Drop | 1 mm | 11 mm | 20 mm | 30 mm | 20 mm | 30 mm | 20 mm | 30 mm |
| Standover Height | 740 mm | 731 mm | 762 mm | 753 mm | 777 mm | 768 mm | 785 mm | 776 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 152 cm | 158 cm | 158 cm | 164 cm | 164 cm | 170 cm | 170 cm |
| Rider Max Height | 163 cm | 163 cm | 169 cm | 169 cm | 175 cm | 175 cm | 181 cm | 181 cm |
About this model
Intrigue X E+ 2, Pro belongs to the Liv E Intrigue model. Liv released 24 e-bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Liv Intrigue X E+ 3 2022 is the cheapest e-bike model and costs 4903$. Liv Intrigue X E+ 1, Pro 2022 is the most expensive one and costs 6400$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail e-bikes
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2022 for 6000$. If we compare this with the average Trail e-bike cost we notice that the price is 78.31% more expensive.
Overview of components
Fork
Liv Intrigue X E+ 2, Pro 2022 e-bike is equipped with the Fox Rhythm Float 36 fork, and has 150mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the Fox Float DPS Performance rear shock model, which has a travel of 140mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The wheels on Intrigue X E+ 2, Pro are the 27.5″ aluminum type. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Liv Intrigue X E+ 2, Pro has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 8 sizes available for this model. Rider height can be anywhere between 152 cm – 181 cm (4.99 ft – 5.94 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Intrigue X E+ 2, Pro. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
