Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora, FSA -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminum
Suspension Fork
Advanced-Grade Composite, Alloy OverDrive Steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Sora
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora
Cassette
Shimano HG400 11x34, 9-speed
Crank
FSA Omega, 32/48
Bottom Bracket
Sealed Cartridge, Threaded
Chain
KMC X9
Pedals
Giant Sport
Wheels
Front Hub
Giant Sport Tracker Disc, 32h
Rear Hub
Giant Sport Tracker Disc, 32h
Rims
Giant SX-2 Disc
Spokes
Sapim Race, 14g
Tires
Giant Sycamore S, 700x38
Brakes
Brakes
Tektro Spyre C, mechanical disc, [F] 160mm, [R] 140mm
Brake Levers
Tektro RL721 Sub Lever
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect, 31.8mm
Seat
Saddle
Liv Connect Upright
Seatpost
Giant Connect, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.46 mm | 1.54 mm | 1.57 mm |
| Bottom Bracket Height | 289 mm | 289 mm | 289 mm | 289 mm |
| Front Center | 584 mm | 591 mm | 598 mm | 620 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 74 mm | 71 mm | 68 mm | 68 mm |
| Stack | 526 mm | 542 mm | 573 mm | 601 mm |
| Reach | 364 mm | 370 mm | 371 mm | 384 mm |
| Top Tube Length | 504 mm | 519 mm | 529 mm | 549 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 370 mm | 420 mm | 465 mm | 500 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 115 mm | 130 mm | 160 mm | 190 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1011 mm | 1018 mm | 1025 mm | 1047 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 672 mm | 708 mm | 746 mm | 777 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Invite 1 is part of the Liv Invite model. 10 bikes variations carry this model name so far. You can easily view all of the Liv Invite bikes models from 2017, here.
Model range prices
Liv Invite 1 2017 is the most economical model, with a starting price of 1100$. Liv Invite CoMax 2017 on the other hand costs 1550$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2017 for 1100$. If we compare this with the average Gravel bike cost we notice that the price is 123.82% lower.
Overview of components
Fork material
Invite 1 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The Invite 1 2017 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Liv Invite 1 is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
This bike is available in 4 sizes. They vary from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, you can easily find one that suits you.
