Liv Langma Advanced Disc 1, Pro Compact 2024
2024 Road
Estimate price |
3,543$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 163cm
SM
158cm - 169cm
MD
164cm - 176cm
LG
170cm - 183cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite, 12x142mm thru-axle, disc
Suspension Fork
Advanced-grade composite, full-composite OverDrive steerer, 12x100mm, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105 Di2
Front Derailleur
Shimano 105 Di2
Shift Levers
Shimano 105 Di2
Cassette
Shimano Di2, 12-speed, 11x34
Crank
Shimano 105, 36/52 XS:165mm, S:170mm, M:170mm, L:172.5mm
Bottom Bracket
Shimano, press fit
Chain
KMC X12
Pedals
N/A
Wheels
Front Hub
Giant alloy, 12mm thru-axle
Rear Hub
Giant alloy, 12mm thru-axle
Rims
Giant P-R2 Disc wheelset, alloy
Spokes
Sapim
Tires
Giant Course 1, tubeless, 700x25c (28mm), folding
Brakes
Brakes
Shimano 105 hydraulic, Giant MPH rotors [F]160mm, [R]140mm
Brake Levers
Shimano 105 Di2
Cockpit
Stem
Giant Contact XS:80mm, S:90mm, M:100mm, L:110mm
Handlebar
Liv Contact XS:36cm, S:38cm, M:40cm, L:42cm
Grips
Liv All Condition
Seat
Saddle
Liv Approach
Seatpost
Giant Variant, composite, -5/+15mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.397 mm | 1.411 mm | 1.448 mm | 1.474 mm |
| Bottom Bracket Height | 264 mm | 266 mm | 266 mm | 269 mm |
| Front Center | 579 mm | 582 mm | 589 mm | 600 mm |
| Rake | 49 mm | 49 mm | 49 mm | 49 mm |
| Trail | 67.8 mm | 61.4 mm | 58.2 mm | 58.2 mm |
| Stack | 517 mm | 532 mm | 553 mm | 569 mm |
| Reach | 370 mm | 377 mm | 382 mm | 386 mm |
| Top Tube Length | 508 mm | 524 mm | 540 mm | 555 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm | 510 mm |
| Head Tube Angle | 71 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 120 mm | 135 mm | 155 mm | 175 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 973 mm | 977 mm | 984 mm | 996 mm |
| Bottom Bracket Drop | 72 mm | 70 mm | 70 mm | 67 mm |
| Standover Height | 700 | 730 mm | 760 mm | 790 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 158 cm | 164 cm | 170 cm |
| Rider Max Height | 163 cm | 169 cm | 176 cm | 183 cm |
About this model
Langma Advanced Disc 1, Pro Compact completes the Liv Langma model. Liv launched 75 bikes of this model so far. Take a sneak peek at all Liv Langma bikes models from 2024, by clicking here.
Model range prices
Liv Langma, Advanced Disc 2 2024 is the most economical model, with a starting price of 2746$. Liv Langma Advanced SL Disc 0 2024 on the other hand costs 13395$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Race bikes
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Liv Langma Advanced Disc 1, Pro Compact price was 3210$. In conclusion, this bike price is 4.36% smaller than the price of the average Race bike.
Overview of components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When leaving the production line, the Langma Advanced Disc 1, Pro Compact model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Langma Advanced Disc 1, Pro Compact comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 152 cm – 183 cm (4.99 ft – 6 ft). In conclusion, you won’t have a problem finding one that suits you.
