Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
145cm - 157cm
XS
152cm - 163cm
SM
158cm - 169cm
MD
164cm - 176cm
LG
170cm - 183cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-Grade Composite, 12x142mm thru-axle, disc
Suspension Fork
Advanced-Grade Composite, full-composite OverDrive steerer, 12x100mm, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano 105
Shift Levers
Shimano 105
Cassette
Shimano 105, 11-speed, 11x34
Crank
Shimano 105, 34/50 XXS:165mm, XS:165mm, S:170mm, M:170mm, L:172.5mm
Bottom Bracket
Shimano, press fit
Chain
KMC X11EL-1
Pedals
N/A
Wheels
Front Hub
Giant P-R2 Disc wheelset, 12mm thru-axle
Rear Hub
Giant P-R2 Disc wheelset, 12mm thru-axle
Rims
Giant P-R2 Disc wheelset
Spokes
Sapim
Tires
Giant Course 1, tubeless, 700x25c (28mm), folding
Brakes
Brakes
Shimano 105 hydraulic, Giant MPH rotors [F]160mm, [R]140mm
Brake Levers
Shimano 105 hydraulic
Cockpit
Stem
Giant Contact XXS:80mm, XS:80mm, S:90mm, M:100mm, L:110mm
Handlebar
Liv Contact XXS:36cm, XS:36cm, S:38cm, M:40cm, L:42cm
Grips
Liv All Condition
Seat
Saddle
Liv Approach
Seatpost
Giant Variant, composite XXS:357mm, XS:357mm, S:357mm, M:357mm, L:357mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.39 mm | 1.4 mm | 1.44 mm | 1.47 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 266 mm | 266 mm | 269 mm |
| Front Center | 576 mm | 579 mm | 582 mm | 589 mm | 600 mm |
| Rake | 49 mm | 49 mm | 49 mm | 49 mm | 49 mm |
| Trail | 74.3 mm | 67.8 mm | 61.4 mm | 58.2 mm | 58.2 mm |
| Stack | 506 mm | 524 mm | 539 mm | 560 mm | 576 mm |
| Reach | 371 mm | 377 mm | 384 mm | 389 mm | 393 mm |
| Top Tube Length | 505 mm | 515 mm | 531 mm | 547 mm | 562 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 390 mm | 420 mm | 450 mm | 480 mm | 510 mm |
| Head Tube Angle | 70 ° | 71 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 105 mm | 120 mm | 135 mm | 155 mm | 175 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 977 mm | 980 mm | 984 mm | 991 mm | 1003 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | 67 mm |
| Standover Height | 687 mm | 707 mm | 737 mm | 767 mm | 797 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 145 cm | 152 cm | 158 cm | 164 cm | 170 cm |
| Rider Max Height | 157 cm | 163 cm | 169 cm | 176 cm | 183 cm |
About this model
Langma, Advanced Disc 2 is part of the Liv Langma model. Liv launched 72 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Liv Langma Advanced Disc 2 Pro Compact 2023 is the cheapest bike model and costs 2653$. Liv Langma Advanced, SL Disc 0 2023 is the most expensive one and costs 8279$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Race bikes
Our math shows that the average cost of a dependable Race bike is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Liv released this model in 2023, its price was 2755$. Comparing the average cost of a Race bike to this one, you will see that Langma, Advanced Disc 2 price is 21.6% smaller.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The Langma, Advanced Disc 2 2023 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Langma, Advanced Disc 2 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Langma, Advanced Disc 2 comes in 5 sizes, that range from 145 cm – 183 cm (4.76 ft – 6 ft). In conclusion, finding one for you shouldn’t be a problem.
