Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite
Suspension Fork
Advanced-grade composite, Hybrid OverDrive steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano 105
Cassette
Shimano 105 11x32, 11-Speed
Crank
Shimano Ultegra, 34/50
Bottom Bracket
Shimano, Press Fit
Chain
KMC X11EL-1
Pedals
N/A
Wheels
Front Hub
Giant Performance Tracker Road Disc, Sealed Bearings, 12mm axles, 28h
Rear Hub
Giant Performance Tracker Road Disc, Sealed Bearings, 12mm axles, 28h
Rims
Giant PR-2 Disc, Tubeless
Spokes
Sapim Race, 14/15g
Tires
Giant Gavia AC 1 Tubeless, 700x25, Folding
Brakes
Brakes
Giant Conduct, hydraulic disc, 140mm
Brake Levers
Shimano 105
Cockpit
Stem
Giant Connect
Handlebar
Giant Contact, 31.8mm
Seat
Saddle
Liv Contact Forward
Seatpost
Giant Variant, composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.4 mm | 1.43 mm | 1.46 mm |
| Bottom Bracket Height | 266 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 577 mm | 579 mm | 586 mm | 596 mm |
| Rake | 49 mm | 45 mm | 45 mm | 45 mm |
| Trail | 66 mm | 64 mm | 60 mm | 60 mm |
| Stack | 501 mm | 518 mm | 539 mm | 558 mm |
| Reach | 364 mm | 371 mm | 377 mm | 381 mm |
| Top Tube Length | 500 mm | 517 mm | 533 mm | 548 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 410 mm | 445 mm | 480 mm | 515 mm |
| Head Tube Angle | 71 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 115 mm | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 398 mm | 398 mm | 398 mm | 398 mm |
| Wheelbase | 965 mm | 967 mm | 974 mm | 984 mm |
| Bottom Bracket Drop | 70 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 672 mm | 694 mm | 721 mm | 747 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Langma Advanced Disc belongs to the Liv Langma model. Liv launched 72 bikes of this model so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Liv Langma Advanced 2 2018 is the most affordable bike of this model and has a price of 1735$. On the other hand, Liv Langma Advanced SL 0 2018, is the most expensive and costs 10000$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Race bikes average price
If you want an acceptable Race bike you should know that the average price is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Liv Langma Advanced Disc price was 2425$. If we compare this with the average Race bike cost we notice that the price is 38.14% smaller.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the Langma Advanced Disc model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Liv Langma Advanced Disc is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, it won’t take much to find one that’s right for you.
