Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Performance Elite Float 34
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-Grade Composite, 120mm Maestro Suspension /ALUXX SL RC
Suspension Fork
Fox 34 Float Performance Elite, 130mm Travel, FIT4 Damper, Boost 15x110 KaBolt, Tapered
Rear Shock
Fox Float Performance Elite, Trunnion Mount
Drivetrain
Rear Derailleur
SRAM GX Eagle
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle, 1x12
Cassette
SRAM GX Eagle, 10x50
Crank
TruVativ Descendent 6k, 30t
Bottom Bracket
SRAM GXP PressFit
Chain
SRAM GX
Chain Guide
None
Pedals
N/A
Wheels
Front Hub
Giant TRX 1 27.5 Carbon WheelSystem [F] Boost 15x110 [R] Boost 12x148, XD Driver Body
Rear Hub
Giant TRX 1 27.5 Carbon WheelSystem [F] Boost 15x110 [R] Boost 12x148, XD Driver Body
Rims
Giant TRX 1 27.5 Carbon WheelSystem [F] Boost 15x110 [R] Boost 12x148, XD Driver Body
Spokes
Giant TRX 1 27.5 Carbon WheelSystem [F] Boost 15x110 [R] Boost 12x148, XD Driver Body
Tires
Maxxis Forekaster 27.5x2.35, 60 TPI, 3C, EXO, TubelessR:2.2
Brakes
Brakes
SRAM Guide RS [F] 180mm [R]180mm
Brake Levers
SRAM Guide RS
Cockpit
Stem
Giant Contact SL
Handlebar
Giant Contact SL Trail
Seat
Saddle
Liv Contact SL (Forward)
Seatpost
Giant Contact S Switch-R Trail Dropper post, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.52 mm | 1.48 mm | 1.48 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm | 334 mm |
| Front Center | 629 mm | 644 mm | 665 mm | 675 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 88 mm | 88 mm | 88 mm | 88 mm |
| Stack | 577 mm | 582 mm | 591 mm | 601 mm |
| Reach | 370 mm | 383 mm | 400 mm | 407 mm |
| Top Tube Length | 548 mm | 568 mm | 588 mm | 598 mm |
| Seat Tube Angle | 73 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 345 mm | 390 mm | 440 mm | 490 mm |
| Head Tube Angle | 69.4 ° | 69.4 ° | 69.4 ° | 69.4 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1054 mm | 1069 mm | 1090 mm | 1100 mm |
| Bottom Bracket Drop | 21 mm | 21 mm | 21 mm | 21 mm |
| Standover Height | 657 mm | 688 mm | 721 mm | 757 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Pique Advanced 1 completes the Liv Pique model. Liv released 32 bikes variations of this model so far. Take a sneak peek at all Liv Pique bikes models from 2018, by clicking here.
Model range prices
The most economical model, the Liv Pique 3 2018 has a starting price of 2245$. Liv Pique Advanced 0 2018 on the other hand is the most expensive at 8160$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Liv released this model in 2018, its price was 5100$. Doing a quick comparison, we notice that Pique Advanced 1 price is 84.65% higher than the average cost of a Trail bike.
Pique Advanced 1 components
Fork
Liv Pique Advanced 1 2018 bike is equipped with the Fox Performance Elite Float 34 fork, and has 130mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The Pique Advanced 1 has a rear shock with a travel of 120mm. The model Fox Float Performance Elite is the one installed in this bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When it comes to wheels, the Pique Advanced 1 bike is equipped with the 27.5″ carbon model. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Liv Pique Advanced 1 includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
