Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Travel Front 80mm -
Fork SunTour XCT
-
Groupset Altus, Shimano -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
One Size
115cm - 130cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum
Suspension Fork
SR XCT L20, coil, 80mm, lockout
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
N/A
Shift Levers
Shimano REVOSHIFT
Cassette
microSHIFT Advent, 12x42
Crank
alloy forged, 30t
Bottom Bracket
cartridge
Chain
KMC Z7
Pedals
platform
Wheels
Front Hub
Giant Disc, 28h, QR, alloy, disc
Rear Hub
Giant Disc, 28h, QR, alloy, disc
Rims
Giant 20", alloy, 28mm inner width
Spokes
stainless, 14g
Tires
Kenda Karma, 20x2.2
Brakes
Brakes
Tektro HD-J285
Brake Levers
Tektro HD-M276
Cockpit
Stem
forged alloy, 0-degree
Handlebar
Giant Sport, alloy, 31.8
Seat
Saddle
Giant Jr. Sport
Seatpost
alloy, 27.2x250
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.44 mm |
| Front Center | 523 mm |
| Rake | 42 mm |
| Trail | 59.8 mm |
| Stack | 444 mm |
| Reach | 309 mm |
| Top Tube Length | 446 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 260 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 361 mm |
| Wheelbase | 883 mm |
| Bottom Bracket Drop | 20 mm |
| Wheels | 20" |
| Rider Min Height | 115 cm |
| Rider Max Height | 130 cm |
About this model
STP 20 FS Liv belongs to the Liv Stp model. Liv launched 12 bikes of this model so far. You can easily view all of the Liv Stp bikes models from 2021, here.
Model range prices
Liv STP 20 Liv 2021 is the cheapest bike model and costs 470$. Liv STP 26 Liv 2021 is the most expensive one and costs 1100$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Youth bikes
According to our calculations, the average cost of a Youth bike that is reliable is 278$. However, even if your budget is less than the average, you might still be able to get a top-quality Youth bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2021 and its price was 575$. Comparing this to the average Youth bike price, we see that the price is 106.83% higher.
Overview of components
Fork
The STP 20 FS Liv comes factory-installed with the SunTour XCT fork. This has a travel range of 80mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The STP 20 FS Liv 2021 bike is equipped with 20″ aluminum wheels when leaving the factory. The 20″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The STP 20 FS Liv comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Liv STP 20 FS Liv 2021 is available in one size only. In conclusion, make sure it fits you, or look for another model.
