Liv Vall E+ Electric Bike 2021
2021 E-bike
Estimate price |
3,761$
Weight | 19.6 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" / 29" -
Travel Front 120mm -
Fork SunTour XCR 32
-
Groupset Deore -
Suspension Hardtail -
Motor Giant 250W 80Nm mid-drive -
Battery Giant EnergyPak Smart 500, 36V Integrated Lithium-Ion -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminium, Overdrive 1½ - 1? inch headtube, 141mm Boost QR, integrated KS18 kickstand mount, compatible with fenders
Suspension Fork
SR Suntour XCR 32 Boost Coil LOR 27.5 / 29 120mm travel, Tapered 1½ - 1? inch steerer, lockout (XS-S: 27.5", M: 29")
Drivetrain
Rear Derailleur
Shimano Deore, 10-Speed, Shadow+
Front Derailleur
chainguide
Shift Levers
Shimano Deore
Cassette
Shimano CS-M4100-10 11-46T 10-Speed
Crank
Forged Alloy minimal Q-factor, 36T Steel Direct Mount
Chain
KMC e.10 Sport, E-bike optimised
Pedals
Aluminium Platform
Wheels
Front Hub
Giant eTracker Sport, [F] 15mm Thru-Axle [R] 141mm QR, e-bike optimised
Rear Hub
Giant eTracker Sport, [F] 15mm Thru-Axle [R] 141mm QR, e-bike optimised
Rims
Giant XCT 29 Tubeless Ready 25mm e-bike optimised, Giant AM 27.5, Tubeless ready, 30mm inner width, e-bike optimised (XS-S: 27.5, M: 29er)
Spokes
Stainless steel
Tires
Maxxis Rekon 29x2.4 / 27.5x2.4, Foldable, EXO, Tubeless Ready (XS-S: 27.5", M: 29") (max tyre width possible: 2.4" rear, 2.5" front)
Brakes
Brakes
Shimano BR-MT200, hydraulic disc, 180mm
Brake Levers
Shimano BL-MT200
Cockpit
Stem
Giant Contact
Handlebar
Giant Connect TR Riser 31.8x690~750mm (XS-S: 690 / M: 750)
Seat
Saddle
Liv Sport
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Motor & Battery
Motor
Giant SyncDrive Sport
Battery
Giant EnergyPak Smart 500, 36V Integrated Lithium-Ion
Remote
wireless display compatible
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.63 mm | 1.65 mm | 1.55 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 329 mm |
| Front Center | 660 mm | 660 mm | 690 mm |
| Rake | 42 mm | 42 mm | 46 mm |
| Trail | 103.8 mm | 103.8 mm | 99.5 mm |
| Stack | 620 mm | 625 mm | 624 mm |
| Reach | 381 mm | 379 mm | 403 mm |
| Top Tube Length | 559 mm | 564 mm | 594 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 365 mm | 405 mm | 445 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 110 mm | 115 mm | 105 mm |
| Chainstay Length | 474 mm | 474 mm | 474 mm |
| Wheelbase | 1129 mm | 1129 mm | 1160 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 45 mm |
| Standover Height | 679 mm | 709 mm | 749 mm |
| Wheels | 27" | 27" | 29" |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
Model Overview
Vall E+ Electric Bike belongs to the Liv E Vall model. There are 8 e-bikes that carry this model name. You can easily view all of the Liv E Vall e-bikes models from 2021, here.
Model range prices
Liv Vall E+ Pro 2021 is the most economical model, with a starting price of 3181$. Liv Vall E+ Pro Electric Bike 2021 on the other hand costs 4352$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail e-bikes average price
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2021 and its price was 3482$. If we compare this with the average Trail e-bike cost we notice that the price is 3.48% higher.
Average weight for Trail e-bikes
Trail e-bikes weigh an average of 23.7 kg (52.25 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Liv Vall E+ Electric Bike it’s weighing 19.6 kg (43.21 lbs). At this weight, is much lighter than average. In short, the average Trail e-bike weight is 20.92% higher than this one.
Overview of components
Fork
The SunTour XCR 32 is included from the factory. It has a travel distance of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Liv Vall E+ Electric Bike 2021, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Liv Vall E+ Electric Bike is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Vall E+ Electric Bike comes in 3 sizes, that range from 151 cm – 179 cm (4.95 ft – 5.87 ft). In conclusion, it won’t take much to find one that’s right for you.
