Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork Suntour XCR
-
Groupset Deore, FSA -
Suspension Hardtail -
Motor Yamaha 250W 70Nm mid-drive -
Battery EnergyPak Smart 625Wh, 36V Integrated Lithium-IonEnergyPak Plus range extender compatible -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 163cm
SM
158cm - 169cm
MD
164cm - 175cm
LG
170cm - 181cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX Aluminum, Overdrive 1½ - 1?" Head Tube, 141mm Boost QR, ISS, EnergyPak Plus Range Extender Compatible, Integrated KS18 Kickstand Mount
Suspension Fork
SR Suntour XCR 32 Coil LO Boost 29/27.5 120mm travel, Tapered 1½ - 1?" steerer, lockout
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore, 10-speed, Shadow+
Front Derailleur
-
Shift Levers
Shimano Deore
Cassette
Shimano CS-M4100-10, 11-46T, 10-speed
Crank
FSA Comet E-Bike crank arm setFSA MegaTooth Direct-mount 1X steel 36T
Bottom Bracket
N/A
Chain
KMC e.10 Sport, e-bike optimized
Pedals
Aluminum Platform
Wheels
Front Hub
Shimano MT410 Boost, Center-Lock, [F] 110x15, Shimano MT200-B [R] 141mm OLD, QR
Rear Hub
Shimano MT410 Boost, Center-Lock, [F] 110x15, Shimano MT200-B [R] 141mm OLD, QR
Rims
Giant XCT 29/27.5 Tubeless Ready 25mm e-bike optimized
Spokes
Stainless steel
Tires
Maxxis Rekon Race 29 x 2.25, Wire Bead, Dual Compound 60TPIMaxxis Rekon Race 27.5 x 2.25, Wire Bead, Dual Compound 60TPI (XS-S: 27.5, M-L: 29)
Brakes
Brakes
Shimano BR-MT200, hydraulic disc, 180mm [F&R]
Brake Levers
Shimano BL-MT200
Cockpit
Stem
Giant Contact
Handlebar
Giant Connect TR Riser 31.8x690, 750mm (XS-S: 690 / M-L: 750)
Grips
Liv Comfort Ergo Microtech Plus
Seat
Saddle
Liv Sport
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Motor & Battery
Motor
SyncDrive Sport, 70Nm, Powered by Yamaha
Battery
EnergyPak Smart 625Wh, 36V Integrated Lithium-IonEnergyPak Plus range extender compatible
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.63 mm | 1.65 mm | 1.55 mm | 1.51 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 329 mm | 329 mm |
| Front Center | 660 mm | 660 mm | 690 mm | 711 mm |
| Rake | 42 mm | 42 mm | 46 mm | 46 mm |
| Trail | 103.8 mm | 103.8 mm | 99.5 mm | 99.5 mm |
| Stack | 620 mm | 625 mm | 624 mm | 633 mm |
| Reach | 381 mm | 379 mm | 403 mm | 420 mm |
| Top Tube Length | 559 mm | 564 mm | 594 mm | 614 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 365 mm | 405 mm | 445 mm | 485 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 110 mm | 115 mm | 105 mm | 115 mm |
| Chainstay Length | 474 mm | 474 mm | 474 mm | 474 mm |
| Wheelbase | 1129 mm | 1129 mm | 1160 mm | 1181 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 45 mm | 45 mm |
| Standover Height | 679 mm | 709 mm | 749 mm | 754 mm |
| Wheels | 27" | 27" | 29" | 29" |
| Rider Min Height | 152 cm | 158 cm | 164 cm | 170 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm |
About this model
Vall E+ EX belongs to the Liv E Vall model. Liv released 8 e-bikes variations of this model so far. Take a sneak peek at all Liv E Vall e-bikes models from 2022, by clicking here.
Model range prices
Liv Vall E+ 1 2022 is the most economical model, with a starting price of 3609$. Liv Vall E+ EX 2022 on the other hand costs 3821$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail e-bikes
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
This e-bike was released in 2022 and its price was 3821$. Comparing the average cost of a Trail e-bike to this one, you will see that Vall E+ EX price is 13.55% more expensive.
Overview of components
Fork
The Vall E+ EX comes factory-installed with the Suntour XCR fork. This has a travel range of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the Vall E+ EX model has 27.5″ aluminum wheels. These wheels will provide you with more control over the e-bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Liv Vall E+ EX is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 4 sizes. They vary from 152 cm – 181 cm (4.99 ft – 5.94 ft). In conclusion, it won’t take much to find one that’s right for you.
