Lynskey Limited Helix GR SRAM Force AXS XPLR 1x 2022
2022 Road
Estimate price |
5,285$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 700c -
Groupset Force XPLR eTap -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 157cm
XS
152cm - 157cm
SM
160cm - 165cm
SM
160cm - 165cm
MD
167cm - 172cm
MD
167cm - 172cm
MD/LG
175cm - 180cm
MD/LG
175cm - 180cm
LG
182cm - 188cm
LG
182cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Titanium
Suspension Fork
Lynskey Pro GR Gravel Fork with 12mm Thru Axle
Drivetrain
Rear Derailleur
SRAM Force XPLR eTap AXS D1 12-Speed Max 44T
Shift Levers
Optional: Please select preferred setup.
Cassette
SRAM XG-1271 D1 Silver 12 Speed 10-44
Crank
SRAM Force AXS 1x Crankset
Bottom Bracket
SRAM DUB Bottom Bracket - BSA 68mm English threaded
Chain
SRAM Force D1 12 Speed Chain
Wheels
Rims
Vision Team 30 Disc Wheelset
Tires
Kenda or WTB 700c depending on availability
Brakes
Brakes
SRAM Force AXS HRD Rear(right) Shifter w/Caliper
Cockpit
Stem
FSA Omega stem +/- 6° Rise 31.8
Handlebar
FSA Omega Compact Alloy Handlebar
Headset
Cane Creek 40 IS 42/28.6- IS 52/40
Seat
Saddle
Lynskey Pro Saddle - Blk
Seatpost
FSA SL-280 27.2 x 350mm x 20mm Setback Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS | SM | SM | MD | MD | MD/LG | MD/LG | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.43 mm | 1.47 mm | 1.47 mm | 1.5 mm | 1.5 mm | 1.53 mm | 1.53 mm | 1.58 mm | 1.58 mm | 1.59 mm | 1.59 mm |
| Bottom Bracket Height | 256 mm | mm | 258 mm | mm | 258 mm | mm | 261 mm | mm | 261 mm | mm | 263 mm | mm |
| Front Center | 595 mm | 595 mm | 605 mm | 605 mm | 612 mm | 612 mm | 625 mm | 625 mm | 633 mm | 633 mm | 650 | 650 |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 66 mm | 59 mm | 69 mm | 62 mm | 65 mm | 58 mm | 65 mm | 58 mm | 63 mm | 56 mm | 63 mm | 56 mm |
| Stack | 529 mm | 529 mm | 549 mm | 549 mm | 569 mm | 569 mm | 589 mm | 589 mm | 614 mm | 614 mm | 634 mm | 634 mm |
| Reach | 369 mm | 369 mm | 374 mm | 374 mm | 379 mm | 379 mm | 384 mm | 384 mm | 389 mm | 389 mm | 399 mm | 399 mm |
| Top Tube Length | 523 mm | 523 mm | 537 mm | 537 mm | 549 mm | 549 mm | 564 mm | 564 mm | 579 mm | 579 mm | 599 mm | 599 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 450 mm | 470 mm | 470 mm | 490 mm | 490 mm | 510 mm | 510 mm | 530 mm | 530 mm | 550 mm | 550 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 110 mm | 110 mm | 126 mm | 126 mm | 145 mm | 145 mm | 169 mm | 169 mm | 193 mm | 193 mm | 217 mm | 217 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1017 mm | 1017 mm | 1027 mm | 1027 mm | 1035 mm | 1035 mm | 1049 mm | 1049 mm | 1056 mm | 1056 mm | 1074 mm | 1074 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 78 mm | 78 mm | 78 mm | 78 mm | 75 mm | 75 mm | 75 mm | 75 mm | 73 mm | 73 mm |
| Standover Height | 715 mm | 715 mm | 736 mm | 736 mm | 757 mm | 757 mm | 779 mm | 779 mm | 799 mm | 799 mm | 823 mm | 823 mm |
| Wheels | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 |
| Rider Min Height | 152 cm | 152 cm | 160 cm | 160 cm | 167 cm | 167 cm | 175 cm | 175 cm | 182 cm | 182 cm | 190 cm | 190 cm |
| Rider Max Height | 157 cm | 157 cm | 165 cm | 165 cm | 172 cm | 172 cm | 180 cm | 180 cm | 188 cm | 188 cm | cm | cm |
About this model
Limited Helix GR SRAM Force AXS XPLR 1x is a Lynskey Limited model. Lynskey released 21 bikes variations of this model so far. Take a sneak peek at all Lynskey Limited bikes models from 2022, by clicking here.
Model range prices
Lynskey Limited Helix GR Shimano GRX 600 1×11 2022 is the most economical model, with a starting price of 5175$. Lynskey Limited Helix GR SRAM Rival AXS XPLR 1x 2022 on the other hand costs 5285$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5285$. Comparing the average cost of a Race bike to this one, you will see that Limited Helix GR SRAM Force AXS XPLR 1x price is 57.76% higher.
Overview of components
Wheels
When leaving the production line, the Limited Helix GR SRAM Force AXS XPLR 1x model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Lynskey Limited Helix GR SRAM Force AXS XPLR 1x has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
