Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 26" -
Travel Front 100mm -
Fork Manitou Circus Expert
-
Suspension Hardtail -
Drivetrain Single Speed -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum Frame, 26” Wheels, 135x10mm Horizontal Dropouts, 73mm Threaded BB, ISCG 05 Tabs
Suspension Fork
Manitou Circus Expert, 26", 100mm Travel, Coil Spring, Taper Steerer Tube, 20x110mm Thru Axle
Drivetrain
Rear Derailleur
-
Front Derailleur
-
Shift Levers
-
Cassette
14T Single Speed Cog
Crank
Marin Forged Alloy, Alloy 32T Chainring, 104mm BCD
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC HL-1
Pedals
Alloy Platform
Wheels
Front Hub
Forged Alloy, 110x20mm, Disc, 32H
Rear Hub
Forged Alloy, 135x10mm, Bolt-On, Quad Sealed Bearings, Disc, 32H
Rims
Marin Custom Extrusion, 27mm Inner, Pinned Joint
Tires
Vee Tire, XCV 26x2.25”, LSG Compound, Wire Bead
Brakes
Brakes
hydraulicDisc
Brake Levers
Tektro HDM275
Cockpit
Stem
Marin 3D Forged Alloy, 40mm
Handlebar
Marin Riser, 6061 Double Butted Aluminum, 38mm Rise, 750mm Width, 4º Up, 9º Back
Grips
Marin Single Clamp Locking
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin DJ Saddle
Seatpost
Marin Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Short | Long |
|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.34 mm |
| Bottom Bracket Height | 317 mm | 317 mm |
| Front Center | 643 mm | 689 mm |
| Rake | 42 mm | 42 mm |
| Trail | 87 mm | 88 mm |
| Stack | 580 mm | 585 mm |
| Reach | 390 mm | 435 mm |
| Top Tube Length | 605 mm | 651 mm |
| Seat Tube Angle | 69 ° | 69 ° |
| Seat Tube Length | 320 mm | 320 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 115 mm | 120 mm |
| Chainstay Length | 400 mm | 400 mm |
| Wheelbase | 1042 mm | 1088 mm |
| Bottom Bracket Drop | 22 mm | 22 mm |
| Standover Height | 375 mm | 405 mm |
| Wheels | 26" | 26" |
Model Overview
Alcatraz completes the Marin Alcatraz model. Marin launched 13 bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Dirt Jump bikes
If you want an acceptable Dirt Jump bike you should know that the average price is 863$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Dirt Jump bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2022 for 1579$. Comparing the average cost of a Dirt Jump bike to this one, you will see that Alcatraz price is 82.97% higher.
Overview of components
Fork
Marin Alcatraz 2022 bike is equipped with the Manitou Circus Expert fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the Alcatraz bike is equipped with the 26″ aluminum model. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Alcatraz is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
