Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox Yari RC
-
Groupset SLX, FSA -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 179cm
LG
176cm - 189cm
XL
187cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 4 6061 Aluminum Frame, 29” Wheels, 150mm Travel MultiTrac Suspension Platform, Internal Dropper Post and Rear Derailleur Housing, Chainstay Mounted Post Mount Disc Brake, 148x12mm Boost Thru- Axle, 73mm Threaded BB w/ ISCG05 Tabs
Suspension Fork
RockShox Yari RC, 29”, 160mm of Travel, Air Sprung, Debonair, Rebound and Compression Adjust, Fast Black Stanchions, 110x15mm Maxle Stealth, 51mm Offset
Rear Shock
X-Fusion O2 PRO RXC, 205x65mm, Rebound Adjustment, Lock Out, Trunnion Upper Mount, 25mm x M8 Lower Mount
Drivetrain
Rear Derailleur
Shimano SLX GS Shadow Plus, 11-Speed
Front Derailleur
-
Shift Levers
Shimano SL-M7000 1x11 Speed I-Spec II
Cassette
e*thirteen TRS Plus 11spd, 9T-46t
Crank
FSA Comet, Modular 1x, 30T Direct Mount Chainring, MegaTooth Technology, Boost Spacing
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X11 Extra Light
Chain Guide
None
Pedals
-
Wheels
Front Hub
Forged Alloy, 110x15mm, 6-Bolt Disc, 32H
Rear Hub
Forged Alloy, 148x12mm, Quad Sealed Cartridge Bearings, 6-Bolt Disc, 32H, XD Driver
Rims
Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, 32H Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
Vee Tire Flow Snap, 29x2.6”, Tackee Compound, 72 TPI, Tubeless Compatible
Brakes
Brakes
Tektro Orion, 4 Piston Hydraulic Disc, 203mm Rotor
Brake Levers
Tektro Orion, I-Spec II Compatible
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 28mm Rise, 780mm Width, 5º Up, 9º Back
Grips
Marin Locking
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
X-Fusion Manic, 1x Composite Remote, Size S 125mm Travel, All Other Sizes: 150mm Travel, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.42 mm | 1.36 mm | 1.31 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 748 mm | 777 mm | 801 mm | 830 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 118 mm | 114 mm | 118 mm | 118 mm |
| Stack | 617.2 mm | 626.3 mm | 635.4 mm | 644.4 mm |
| Reach | 422 mm | 442 mm | 467 mm | 492 mm |
| Top Tube Length | 570.76 mm | 602.65 mm | 628.63 mm | 659.4 mm |
| Seat Tube Angle | 76.41 ° | 76 ° | 75.68 ° | 75.39 ° |
| Seat Tube Length | 385 mm | 420 mm | 450 mm | 480 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1177 mm | 1206 mm | 1230 mm | 1260 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 703 mm | 724 mm | 745 mm | 758 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 166 cm | 176 cm | 187 cm |
| Rider Max Height | 169 cm | 179 cm | 189 cm | 193 cm |
About this model
Alpine Trail 7 is part of the Marin Alpine model. Marin launched 22 bikes of this model so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Marin Alpine Trail 7 2019 is the cheapest bike model and costs 2899$. Marin Alpine Trail 8 2019 is the most expensive one and costs 3899$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro bikes average price
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2019 and its price was 2899$. If we compare this with the average Enduro bike cost we notice that the price is 24.15% lower.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
This bike has the RockShox Yari RC fork installed. The fork’s travel is 160mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
From the factory, it comes with the X-Fusion O2 PRO RXC rear shock model, which has a travel of 150mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, Marin Alpine Trail 7 2019, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Alpine Trail 7 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 160 cm – 193 cm (5.25 ft – 6.33 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
A dropper post is included with the Alpine Trail 7. Therefore, climbing or descending will be a breeze.
