Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Claris, FSA -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum, Endurance Fit Geometry
Suspension Fork
Carbon w/ Alloy Steerer
Drivetrain
Rear Derailleur
Shimano Claris
Front Derailleur
Shimano Claris
Shift Levers
Shimano Claris 8-Speed
Cassette
Sunrace 8-Speed, 11-32T
Crank
FSA Temp Compact, 50/34T
Bottom Bracket
Sealed Cartridge Bearing, Square Taper
Chain
KMC Z8
Pedals
Resin Road
Wheels
Front Hub
Formula, 28H
Rear Hub
Formula, 32H
Rims
Maddux DRX20, Double Wall, Machined Sidewall, 20mm Height
Tires
Schwalbe Lugano, 700x25C, Kevlar Puncture Protection
Brakes
Brakes
Tektro R312 Dual Pivot
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Alloy
Handlebar
Marin Compact Drop
Grips
Marin Silicon Gel Tape
Headset
FSA No.8B
Seat
Saddle
Marin Endurance Concept
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.43 mm | 1.47 mm | 1.5 mm | 1.55 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 587 mm | 595 mm | 600 mm | 605 mm | 615 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 74 mm | 62 mm | 62 mm | 62 mm | 56 mm |
| Stack | 528.5 mm | 554.7 mm | 569 mm | 583.3 mm | 615.6 mm |
| Reach | 369.7 mm | 387.6 mm | 388.1 mm | 388 mm | 398.1 mm |
| Top Tube Length | 511 mm | 536 mm | 551 mm | 566 mm | 586 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74 ° | 73 ° | 73 ° |
| Seat Tube Length | 435 mm | 485 mm | 525 mm | 555 mm | 585 mm |
| Head Tube Angle | 70 ° | 72 ° | 72 ° | 72 ° | 73 ° |
| Head Tube Length | 135 mm | 155 mm | 170 mm | 185 mm | 215 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm |
| Wheelbase | 993 mm | 1001 mm | 1006 mm | 1011 mm | 1021 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 719 mm | 757 mm | 783 mm | 804 mm | 834 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Argenta belongs to the Marin Argenta model. 10 bikes variations carry this model name so far. Take a sneak peek at all Marin Argenta bikes models from 2016, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
General Road bikes average price
Our math shows that the average cost of a dependable General Road bike is 1915$. However, you could also get a good General Road bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, Marin Argenta 2016, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Argenta has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Marin Argenta bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
