Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Claris, FSA -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 Endurance Road, 6061 Aluminum, Butted and Formed Tubing, 700C Wheels, Fender and Rack Mounts, Forged Dropouts, Clearance For Up to 35mm Tire
Suspension Fork
Carbon w/ Alloy Steerer, Integrated Fender Eyelets, Clearance For Up To 35mm Tire
Drivetrain
Rear Derailleur
Shimano Claris 8-Speed
Front Derailleur
Shimano Claris
Shift Levers
Shimano Claris 2x8-Speed
Cassette
SunRace 8-Speed, 11-32T
Crank
FSA Tempo Compact, 50/34T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z8
Wheels
Front Hub
Forged Aluminum Alloy, 28H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, 20mm Tall, Machined Sidewall
Spokes
14g Stainless Steel
Tires
Schwalbe Lugano, 700Cx25, Kevlar Puncture Protection
Brakes
Brakes
Tektro Dual Pivot
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Alloy
Handlebar
Marin Compact Drop
Grips
Marin Silicon Gel Tape
Headset
FSA No.8B
Seat
Saddle
Marin Endurance Concept
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.64 mm | 1.61 mm | 15.702 mm | 1.57 mm | 1.56 mm | 1.56 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 535 mm | 550 mm | 568 mm | 588 mm | 600 mm | 620 mm | 629 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 62 mm | 62 mm | 60 mm | 1740 mm | 59 mm | 59 mm | 59 mm |
| Stack | 552.3 mm | 566.6 mm | 581.7 mm | mm | 606.5 mm | 625.6 mm | 635.1 mm |
| Reach | 334.5 mm | 345.3 mm | 360.5 mm | 377.6 mm | 387.4 mm | 401.6 mm | 407.6 mm |
| Top Tube Length | 486 mm | 506 mm | 531 mm | 551 mm | 571 mm | 591 mm | 606 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 72 ° | 72 ° | 72.25 ° | 72.25 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 135 mm | 150 mm | 165 mm | 175 mm | 190 mm | 210 mm | 220 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 944 mm | 960 mm | 977 mm | 997 mm | 1009 mm | 1030 mm | 1039 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 750 mm | 771 mm | 788 mm | 802 mm | 818 mm | 837 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Argenta is part of the Marin Argenta model. Marin released 10 bikes variations of this model so far. Take a sneak peek at all Marin Argenta bikes models from 2018, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
General Road bikes average price
If you want an acceptable General Road bike you should know that the average price is 1915$. However, you could also get a good General Road bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork material
Argenta has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When it comes to wheels, the Argenta bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
