Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Sora, Shimano -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 Endurance Road, 6061 Aluminum, Butted and Formed Tubing, 700C Wheels, Fender and Rack Mounts, Forged Dropouts, Clearance For Up to 35mm Tire
Suspension Fork
Carbon w/ Alloy Steerer, Integrated Fender Eyelets, Clearance For Up To 35mm Tire
Drivetrain
Rear Derailleur
Shimano Sora 9-Speed
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora 2x9-Speed
Cassette
Shimano HG-50 9-Speed, 11-30T
Crank
Shimano R345 Compact, 50/34T
Bottom Bracket
Shimano Octalink V2 Cartridge
Chain
KMC X9
Pedals
Road Flat
Wheels
Front Hub
Forged Aluminum Alloy, 28H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, 20mm Tall, Machined Sidewall
Spokes
14g Black Stainless Steel
Tires
Schwalbe Lugano, 700Cx25, Kevlar Puncture Protection
Brakes
Brakes
Tektro Dual Pivot, Cartridge Pads
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Compact Drop
Grips
Marin Silicon Gel Tape
Headset
FSA No.8B
Seat
Saddle
Marin Endurance Concept
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.64 mm | 1.61 mm | 1.57 mm | 1.57 mm | 1.56 mm | 1.56 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 535 mm | 550 mm | 568 mm | 588 mm | 600 mm | 620 mm | 629 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 62 mm | 62 mm | 60 mm | 60 mm | 59 mm | 59 mm | 59 mm |
| Stack | 552.3 mm | 566.6 mm | 581.5 mm | 591.3 mm | 606.5 mm | 625.6 mm | 635.1 mm |
| Reach | 334.5 mm | 345.3 mm | 360.5 mm | 377.6 mm | 387.4 mm | 401.6 mm | 407.6 mm |
| Top Tube Length | 486 mm | 506 mm | 531 mm | 551 mm | 571 mm | 591 mm | 606 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 72 ° | 72 ° | 72.25 ° | 72.25 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 135 mm | 150 mm | 165 mm | 175 mm | 190 mm | 210 mm | 220 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 944 mm | 960 mm | 977 mm | 997 mm | 1009 mm | 1030 mm | 1039 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 750 mm | 771 mm | 788 mm | 802 mm | 818 mm | 837 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Argenta Comp completes the Marin Argenta model. Marin released 10 bikes variations of this model so far. You can easily view all of the Marin Argenta bikes models from 2018, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for General Road bikes
According to our math, the average price for a trustworthy General Road bike is 1915$. However, this doesn’t mean that if you spend less money on a General Road bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Argenta Comp components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
As for the wheels, Marin Argenta Comp 2018, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Argenta Comp has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
