Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 150mm -
Fork X Fusion
-
Groupset NX, FSA -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 4 6061 Aluminum Frame, 27.5” Wheels, 150mm Travel QUAD 3 Suspension Platform, Internal Dropper Post and Rear Der Housing, Chainstay Mounted Post Mount Disc Brake, 148x12mm Boost Thru-Axle
Suspension Fork
X-Fusion Metric R, 27.5", 160mm Travel, Air Spring, Rebound Adjustment, 110x20mm Boost Thru-Axle, Black Ano Stanchions
Rear Shock
X-Fusion O2 PRO RL, 200x57mm, Rebound Adjustment, Lock Out, 25.4mm x M8 Upper and 19mm x M8 Lower Hardware
Drivetrain
Rear Derailleur
SRAM NX 11-Speed
Front Derailleur
- - -
Shift Levers
SRAM NX 1x11-Speed
Cassette
SunRace 11-Speed, 11-42T
Crank
FSA Comet, Modular 1x, 30T Direct Mount Chainring, MegaTooth Technology, Boost Spacing
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X11 Extra Light
Chain Guide
No
Pedals
- - -
Wheels
Front Hub
Formula, 110x20mm, 6-Bolt Disc, 32H
Rear Hub
Formula, 148x12mm, Quad Sealed Cartridge Bearings, 6-Bolt Disc, 32H
Rims
Marin Aluminum Double Wall, 35mm Inner Front, 29mm Rear, Pinned Joint, Disc Specific, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
Schwalbe Hans Dampf, 27.5”x2.35”, Performance Wire Bead, Tubeless Compatible
Brakes
Brakes
Shimano Deore MT500 Hydraulic Disc, 203mm Rotor
Brake Levers
Shimano Deore MT500 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 25mm Rise, 780mm Width, 4º Up, 9º Back
Grips
Marin Locking
Headset
FSA No 57E, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
WTB Volt Comp
Seatpost
TranzX Dropper Post, YSP15 w/ 1x Remote, Size S 350mm Length 100mm Travel, All Other Sizes: 400mm Length 120mm Travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.35 mm | 1.32 mm | 1.3 mm |
| Bottom Bracket Height | 335.5 mm | 335.5 mm | 335.5 mm | 335.5 mm |
| Front Center | 723 mm | 747 mm | 771 mm | 799 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 111 mm | 111 mm | 112 mm | 111 mm |
| Stack | 592.9 mm | 602 mm | 613 mm | 629.4 mm |
| Reach | 425 mm | 445 mm | 465 mm | 485 mm |
| Top Tube Length | 585.2 mm | 613.9 mm | 640 mm | 670 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 405 mm | 445 mm | 480 mm | 520 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 135 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1162 mm | 1186 mm | 1210 mm | 1238 mm |
| Bottom Bracket Drop | 14 mm | 14 mm | 14 mm | 14 mm |
| Standover Height | 703 mm | 735 mm | 764 mm | 784 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Attack Trail 7 is part of the Marin Attack model. Marin launched 14 bikes of this model so far. Take a sneak peek at all Marin Attack bikes models from 2018, by clicking here.
Model range prices
Marin Attack Trail 7 2018 is the most economical model, with a starting price of 2649$. Marin Attack Trail 8 2018 on the other hand costs 4199$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro bikes average price
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Marin Attack Trail 7 price was 2649$. If we compare this with the average Enduro bike cost we notice that the price is 35.86% smaller.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Attack Trail 7 components
Fork
This bike has the X Fusion fork installed. The fork’s travel is 160mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
From the factory, it comes with the X-Fusion O2 PRO RL rear shock model, which has a travel of 150mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When leaving the production line, the Attack Trail 7 model has 27.5″ aluminum wheels. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Attack Trail 7 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Attack Trail 7. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
