Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork Suntour XCR
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 165cm
MD
169cm - 180cm
MD
169cm - 180cm
LG
175cm - 184cm
XL
181cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 6061 Aluminum, 27.5" or 29” Wheels, Low Standover, 68mm BB shell, 135mm Forged Dropouts, IS Chainstay Disc Mount, Internal Housing & Dropper Post Routing
Suspension Fork
SR/Suntour XCR LOR-DS, Thru-Axle, 120mm Travel, Hydraulic Lockout, Damping Adjustment, 42mm (27.5") and 46mm (29") Offsets
Drivetrain
Rear Derailleur
Shimano Deore 11-Speed w/Clutch
Front Derailleur
-
Shift Levers
Shimano Deore 11-Speed
Cassette
SunRace 11-Speed, 11-51T
Crank
Marin Forged Alloy 1x11, Hollow Spindle, Steel Narrow Wide 32T Chainring
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X11
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, Disc, 32H
Rear Hub
Forged Alloy, Disc, 32H
Rims
Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Tires
MTB, 27.5/29x2.25"
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano BL-MT201
Cockpit
Stem
Marin Alloy, 31.8mm Clamp, 45mm
Handlebar
Marin 31.8 Riser, 12mm Rise, 780mm Width
Grips
Marin MTB, Closed End
Headset
FSA No.10-P
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.36 mm | 1.42 mm | 1.37 mm | 1.33 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 311.5 mm | 311.5 mm | 311.5 mm |
| Front Center | 713 mm | 725 mm | 744 mm | 766 mm | 783 mm |
| Rake | 44 mm | 44 mm | 51 mm | 51 mm | 51 mm |
| Trail | 100 mm | 100 mm | 104 mm | 104 mm | 104 mm |
| Stack | 597.3 mm | 602 mm | 627.3 mm | 632 mm | 636.5 mm |
| Reach | 433 mm | 443 mm | 443 mm | 463 mm | 478 mm |
| Top Tube Length | 599 mm | 610.5 mm | 617.5 mm | 638.8 mm | 655 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 381 mm | 431 mm | 431 mm | 482 mm | 520 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 105 mm | 110 mm | 110 mm | 115 mm | 120 mm |
| Chainstay Length | 423 mm | 423 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1131 mm | 1143 mm | 1175 mm | 1197 mm | 1214 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 61 mm | 61 mm | 61 mm |
| Standover Height | 657 mm | 703 mm | 712 mm | 742 mm | 772 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 169 cm | 169 cm | 175 cm | 181 cm |
| Rider Max Height | 165 cm | 180 cm | 180 cm | 184 cm | 190 cm |
About this model
Bobcat Trail 5 is part of the Marin Bobcat model. 36 bikes variations carry this model name so far. You can easily view all of the Marin Bobcat bikes models from 2023, here.
Model range prices
Marin Bobcat Trail 3 2023 is the most economical model, with a starting price of 699$. Marin Bobcat Trail 5 2023 on the other hand costs 999$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Marin Bobcat Trail 5 price was 999$. Comparing the average cost of a Trail bike to this one, you will see that Bobcat Trail 5 price is 176.48% smaller.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The fork installed on this bike is the Suntour XCR model. The travel on this model is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When it comes to wheels, the Bobcat Trail 5 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Bobcat Trail 5 comes in 5 sizes, that range from 157 cm – 190 cm (5.15 ft – 6.23 ft). In short, you can easily find one that suits you.
