Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork Suntour XCR
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 165cm
MD
169cm - 180cm
MD
169cm - 180cm
LG
175cm - 184cm
XL
181cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 6061 Aluminum, 27.5" or 29” Wheels, Low Standover, 68mm BB shell, 135mm Forged Dropouts, IS Chainstay Disc Mount, Internal Housing & Dropper Post Routing
Suspension Fork
SR/Suntour XCR LOR-DS, Thru-Axle, 120mm Travel, Hydraulic Lockout, Damping Adjustment, 42mm (27.5") and 46mm (29") Offsets
Drivetrain
Rear Derailleur
Shimano Deore 11-Speed w/Clutch
Front Derailleur
-
Shift Levers
Shimano Deore 11-Speed
Cassette
SunRace 11-Speed, 11-51T
Crank
Marin Forged Alloy 1x11, Hollow Spindle, Steel Narrow Wide 32T Chainring
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X11
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, Disc, 32H
Rear Hub
Forged Alloy, Disc, 32H
Rims
Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Tires
MTB, 27.5/29x2.25"
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano BL-MT201
Cockpit
Stem
Marin Alloy, 31.8mm Clamp, 45mm
Handlebar
Marin 31.8 Riser, 12mm Rise, 780mm Width
Grips
Marin MTB, Closed End
Headset
FSA No.10-P
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.36 mm | 1.42 mm | 1.37 mm | 1.33 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 311.5 mm | 311.5 mm | 311.5 mm |
| Front Center | 713 mm | 725 mm | 744 mm | 766 mm | 783 mm |
| Rake | 44 mm | 44 mm | 51 mm | 51 mm | 51 mm |
| Trail | 100 mm | 100 mm | 104 mm | 104 mm | 104 mm |
| Stack | 597.3 mm | 602 mm | 627.3 mm | 632 mm | 636.5 mm |
| Reach | 433 mm | 443 mm | 443 mm | 463 mm | 478 mm |
| Top Tube Length | 599 mm | 610.5 mm | 617.5 mm | 638.8 mm | 655 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 381 mm | 431 mm | 431 mm | 482 mm | 520 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 105 mm | 110 mm | 110 mm | 115 mm | 120 mm |
| Chainstay Length | 423 mm | 423 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1131 mm | 1143 mm | 1175 mm | 1197 mm | 1214 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 61 mm | 61 mm | 61 mm |
| Standover Height | 657 mm | 703 mm | 712 mm | 742 mm | 772 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 169 cm | 169 cm | 175 cm | 181 cm |
| Rider Max Height | 165 cm | 180 cm | 180 cm | 184 cm | 190 cm |
Model Overview
Bobcat Trail 5 is part of the Marin Bobcat model. There are 36 bikes that carry this model name. Take a sneak peek at all Marin Bobcat bikes models from 2024, by clicking here.
Model range prices
Marin Bobcat Trail 3 2024 is the most affordable bike of this model and has a price of 699$. On the other hand, Marin Bobcat Trail 5 2024, is the most expensive and costs 899$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Marin Bobcat Trail 5 price was 899$. If we compare this with the average Trail bike cost we notice that the price is 207.23% lower.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Bobcat Trail 5 components
Fork
The Suntour XCR is included from the factory. It has a travel distance of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The wheels on Bobcat Trail 5 are the 27.5″ aluminum type. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Bobcat Trail 5 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 157 cm – 190 cm (5.15 ft – 6.23 ft). In short, you can easily find one that suits you.
