Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum w/ SHOT Tech, 27.5” Wheels
Suspension Fork
SR Suntour XCM 27.5”, LO Damper, Lockout, 100mm Travel (80mm Travel Size XS)
Drivetrain
Rear Derailleur
Shimano Acera Shadow
Front Derailleur
Shimano Altus
Shift Levers
Shimano Altus 9-Speed
Cassette
Sunrace 9-Speed, 11-36T
Crank
Forged Alloy, 44/32/22T
Bottom Bracket
Sealed Cartridge Bearing, Square Taper
Chain
KMC X9
Pedals
Resin Platform
Wheels
Front Hub
Formula, 6-Bolt Disc, 32H
Rear Hub
Formula, 6-Bolt Disc, 32H
Rims
Maddux Double Wall, Machined Sidewall
Tires
Schwalbe Rapid Rob, 27.5x2.25”
Brakes
Brakes
Tektro Auriga Hydraulic Disc, 180mm Rotor
Brake Levers
Tektro Auriga Hydraulic
Cockpit
Stem
Marin Alloy
Handlebar
Marin Mini-Riser, 10mm Rise 740mm Width
Grips
Marin Dual Density
Headset
FSA No.10-P
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.43 mm | 1.39 mm | 1.4 mm | 1.42 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 305 mm | 305 mm |
| Front Center | 657 mm | 674 mm | 694 mm | 713 mm | 727 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 89 mm | 89 mm | 89 mm | 89 mm | 89 mm |
| Stack | 592.41 mm | 592.41 mm | 601.75 mm | 620.42 mm | 639.09 mm |
| Reach | 397.71 mm | 414.71 mm | 431.85 mm | 443.14 mm | 450.43 mm |
| Top Tube Length | 579.1 mm | 596.1 mm | 616.1 mm | 633.1 mm | 646.1 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 382.1 mm | 431.8 mm | 483 mm | 521 mm | 559 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1081 mm | 1098 mm | 1119 mm | 1137 mm | 1152 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Standover Height | 684 mm | 724 mm | 766 mm | 800 mm | 833 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
About this model
Bobcat Trail 7.4 completes the Marin Bobcat model. Marin launched 36 bikes of this model so far. Check out the entire range from 2016 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
This bike has the SunTour XCM fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on Bobcat Trail 7.4 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Bobcat Trail 7.4 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
