Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Travel Front 100mm -
Fork SunTour
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
158cm - 167cm
SM
165cm - 173cm
MD
169cm - 180cm
MD
169cm - 180cm
LG
177cm - 186cm
XL
183cm - 191cm
XXL
186cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, 27.5”/29" Wheels, Low Standover, 68mm BB shell, 135mm Forged Dropouts, Chainstay Mounted Disc Brakes
Suspension Fork
SR Suntour XCE Disc, 100mm Travel, Preload Adjustment, 46mm Offset
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
Shimano FD-TX500
Shift Levers
Shimano Tourney 3x7-Speed
Cassette
SunRace 7-Speed, 11-34T
Crank
Shimano FC-TY301, 42/34/24T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z51
Pedals
Nylon Platform
Wheels
Front Hub
Formula, 32H
Rear Hub
Formula, 32H
Rims
Marin, Double Wall Alloy
Spokes
15g Black Stainless Steel
Tires
MTB, 27.5/29x2.25"
Brakes
Brakes
Power CX7 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Alloy, 31.8 Bar Bore, 45mm
Handlebar
Marin 31.8 Riser, 12mm Rise, 780mm Width
Grips
Marin Dual Density
Headset
FSA No.10-P
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.41 mm | 1.37 mm | 1.43 mm | 1.4 mm | 1.35 mm | 1.33 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 307 mm | 311.5 mm | 311.5 mm | 311.5 mm | 311.5 mm |
| Front Center | 659 mm | 676 mm | 693 mm | 712 mm | 729 mm | 751 mm | 762 mm |
| Rake | 44 mm | 44 mm | 44 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 83 mm | 83 mm | 83 mm | 78 mm | 78 mm | 78 mm | 79 mm |
| Stack | 578.8 mm | 583.5 mm | 588 mm | 614 mm | 618.5 mm | 623 mm | 628 mm |
| Reach | 398 mm | 413 mm | 428 mm | 428 mm | 443 mm | 463 mm | 473 mm |
| Top Tube Length | 564.5 mm | 581 mm | 597.2 mm | 604.6 mm | 621 mm | 642.2 mm | 653.6 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 330 mm | 381 mm | 431 mm | 431 mm | 481 mm | 520 mm | 559 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm | 110 mm | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 453 mm | 453 mm | 453 mm | 453 mm |
| Wheelbase | 1082 mm | 1099 mm | 1116 mm | 1158 mm | 1175 mm | 1197 mm | 1208 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 61 mm | 61 mm | 61 mm | 61 mm |
| Standover Height | 647 mm | 661 mm | 704 mm | 714 mm | 742 mm | 771 mm | 804 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 165 cm | 169 cm | 169 cm | 177 cm | 183 cm | 186 cm |
| Rider Max Height | 167 cm | 173 cm | 180 cm | 180 cm | 186 cm | 191 cm | 194 cm |
Model Overview
Bolinas Ridge 1 belongs to the Marin Bolinas model. There are 22 bikes that carry this model name. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Marin Bolinas Ridge 1 2020 is the most affordable bike of this model and has a price of 429$. On the other hand, Marin Bolinas Ridge 2 2020, is the most expensive and costs 499$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2020 for 429$. Comparing the average cost of a Hybrid bike to this one, you will see that Bolinas Ridge 1 price is 31% lower.
Overview of components
Fork
The Bolinas Ridge 1 comes factory-installed with the SunTour fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Bolinas Ridge 1 2020 bike is equipped with aluminum wheels when leaving the factory. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Bolinas Ridge 1 has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Marin Bolinas Ridge 1 bike has 7 sizes, in the range of 158 cm – 194 cm (5.18 ft – 6.36 ft). In short, it won’t be difficult to find the right one for you.
