Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
158cm - 167cm
SM
165cm - 173cm
MD
169cm - 180cm
LG
177cm - 186cm
XL
183cm - 191cm
XXL
186cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, 27.5” Wheels, 68mm BB shell, 135mm Forged Dropouts
Suspension Fork
SR Suntour XCT HLO 27.5”, 100mm Travel, Hydraulic Lockout
Drivetrain
Rear Derailleur
Shimano Altus, 8-Speed
Front Derailleur
Shimano FD-TY700
Shift Levers
Shimano ST-EF51 3x8-Speed
Cassette
SunRace 8-Speed, 11-32T
Crank
Shimano FC-TY301, 42/34/24T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z7
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, 6-Bolt Disc, 32H
Rear Hub
Forged Alloy, 6-Bolt Disc, 32H
Rims
Marin, Double Wall Alloy
Spokes
15g Black Stainless Steel
Tires
Mountain Tire, 27.5”x2.1"
Brakes
Brakes
Tektro Aires Mechanical Disc, 160mm Rotor
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Alloy, 60mm
Handlebar
Marin Riser, 25mm Rise, 700mm Width
Grips
Marin MTB, Closed End
Headset
FSA No.10-P
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.43 mm | 1.39 mm | 1.34 mm | 1.31 mm | 1.29 mm |
| Bottom Bracket Height | 304.5 mm | 304.5 mm | 304.5 mm | 304.5 mm | 304.5 mm | 304.5 mm |
| Front Center | 651 mm | 666 mm | 684 mm | 704 mm | 721 mm | 733 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 89 mm | 89 mm | 89 mm | 89 mm | 89 mm | 89 mm |
| Stack | 581.04 mm | 585.71 mm | 590.38 mm | 595.05 mm | 599.72 mm | 604.38 mm |
| Reach | 394.75 mm | 408.32 mm | 423.89 mm | 442.46 mm | 458.04 mm | 467.61 mm |
| Top Tube Length | 573 mm | 588 mm | 605 mm | 625 mm | 642 mm | 653 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 330 mm | 381 mm | 431 mm | 482 mm | 520 mm | 559 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1074 mm | 1089 mm | 1107 mm | 1127 mm | 1145 mm | 1156 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Standover Height | 643 mm | 683 mm | 725 mm | 766 mm | 796 mm | 826 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 165 cm | 169 cm | 177 cm | 183 cm | 186 cm |
| Rider Max Height | 167 cm | 173 cm | 180 cm | 186 cm | 191 cm | 194 cm |
Model Overview
Bolinas Ridge 2 belongs to the Marin Bolinas model. Marin released 22 bikes variations of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Marin Bolinas Ridge 1 2019 is the cheapest bike model and costs 429$. Marin Bolinas Ridge 2 2019 is the most expensive one and costs 499$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 499$. Comparing this to the average Crosscountry bike price, we see that the price is 281.76% smaller.
Bolinas Ridge 2 components
Fork
Marin Bolinas Ridge 2 2019 bike is equipped with the SunTour XCT fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the Bolinas Ridge 2 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Bolinas Ridge 2 has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Bolinas Ridge 2 comes in 6 sizes, that range from 158 cm – 194 cm (5.18 ft – 6.36 ft). In conclusion, it won’t take much to find one that’s right for you.
