Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 159cm
SM
156cm - 165cm
MD
169cm - 179cm
MD
169cm - 179cm
LG
175cm - 184cm
XL
181cm - 182cm
XXL
186cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, 27.5”/29" Wheels, Low Standover, 68mm BB shell, 135mm Forged Dropouts, Chainstay Mounted Disc Brakes
Suspension Fork
SR Suntour XCM DS, 100mm Travel, Preload Adjustment, 46mm Offset
Drivetrain
Rear Derailleur
Shimano Altus, 8-Speed
Front Derailleur
Shimano FD-TY700
Shift Levers
Shimano Altus 3x8-Speed
Cassette
SunRace 8-Speed, 11-34T
Crank
Alloy Crank, Steel Chainrings, 42/34/24T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z8
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, Disc, 32H
Rear Hub
Forged Alloy, Disc, 32H
Rims
Marin, Double Wall Alloy
Tires
MTB, 27.5/29x2.25"
Brakes
Brake Levers
Tektro M275 Hydraulic Disc
Cockpit
Stem
Marin Alloy, 31.8mm, 45mm
Handlebar
Marin 31.8 Riser, 12mm Rise, 780mm Width
Grips
Marin MTB, Closed End
Headset
FSA No.10-P
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.41 mm | 1.37 mm | 1.43 mm | 1.4 mm | 1.35 mm | 1.33 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 307 mm | 311.5 mm | 311.5 mm | 311.5 mm | 311.5 mm |
| Front Center | 659 mm | 676 mm | 693 mm | 712 mm | 729 mm | 751 mm | 762 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 93 mm | 93 mm | 93 mm | 89 mm | 89 mm | 89 mm | 90 mm |
| Stack | 578.8 mm | 583.5 mm | 588 mm | 614 mm | 618.5 mm | 623 mm | 628 mm |
| Reach | 398 mm | 413 mm | 428 mm | 428 mm | 443 mm | 463 mm | 473 mm |
| Top Tube Length | 564.5 mm | 581 mm | 597.2 mm | 604.6 mm | 621 mm | 642.2 mm | 653.6 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 330 mm | 381 mm | 431 mm | 431 mm | 481 mm | 520 mm | 559 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm | 110 mm | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 453 mm | 453 mm | 453 mm | 453 mm |
| Wheelbase | 1082 mm | 1099 mm | 1116 mm | 1158 mm | 1175 mm | 1197 mm | 1208 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 61 mm | 61 mm | 61 mm | 61 mm |
| Standover Height | 647 mm | 661 mm | 704 mm | 714 mm | 742 mm | 771 mm | 804 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 147 cm | 156 cm | 169 cm | 169 cm | 175 cm | 181 cm | 186 cm |
| Rider Max Height | 159 cm | 165 cm | 179 cm | 179 cm | 184 cm | 182 cm | 194 cm |
About this model
Bolinas Ridge 2 completes the Marin Bolinas model. Marin released 22 bikes variations of this model so far. Take a sneak peek at all Marin Bolinas bikes models from 2022, by clicking here.
Model range prices
Marin Bolinas Ridge 1 2022 is the cheapest bike model and costs 599$. Marin Bolinas Ridge 2 2022 is the most expensive one and costs 699$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Marin released this model in 2022, its price was 699$. Comparing the average cost of a Crosscountry bike to this one, you will see that Bolinas Ridge 2 price is 172.53% lower.
Overview of components
Fork
The fork installed on this bike is the SunTour XCM model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
As for the wheels, Marin Bolinas Ridge 2 2022, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Bolinas Ridge 2 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 7 sizes. They vary from 147 cm – 194 cm (4.82 ft – 6.36 ft). In short, you can easily find one that suits you.
