Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset microSHIFT Advent -
Suspension Rigid -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 169cm
MD
166cm - 179cm
LG
176cm - 188cm
XL
185cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 DSX, 6061 Aluminum, Internal Cable Routing, Mudguard and Rack Mounts, IS Disc Mount
Suspension Fork
6061 Aluminum, Straight-Blade, Disc Mount, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
microSHIFT Advent 9, Clutch
Front Derailleur
-
Shift Levers
microSHIFT Advent 9 Trail
Cassette
SunRace 9-Speed, 11-46T
Crank
Alloy Crank, Steel Narrow-Wide Chainring, 38T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X9
Pedals
Marin Oso OE Flat
Wheels
Front Hub
Forged Aluminum Alloy, Disc, 32H
Rear Hub
Forged Aluminum Alloy, Disc, 32H
Rims
Marin Aluminum Double Wall, Disc Specific
Tires
WTB Riddler, 700Cx45mm
Brakes
Brakes
Hydraulic Disc
Brake Levers
Clark's Clout Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Mini Riser
Grips
Marin MTB
Headset
FSA, Orbit CE No.8B
Seat
Saddle
Marin DSX
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.42 mm | 1.43 mm | 1.45 mm |
| Bottom Bracket Height | 279.5 mm | 279.5 mm | 279.5 mm | 279.5 mm |
| Front Center | 612 mm | 648 mm | 673 mm | 698 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 77 mm | 77 mm | 77 mm | 77 mm |
| Stack | 540.4 mm | 568.5 mm | 596.6 mm | 624.7 mm |
| Reach | 376 mm | 401 mm | 416 mm | 431 mm |
| Top Tube Length | 532.1 mm | 565.2 mm | 588.2 mm | 611.3 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 480 mm | 520 mm | 558 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 120 mm | 150 mm | 180 mm | 210 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1020 mm | 1056 mm | 1081 mm | 1106 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 654 mm | 696 mm | 726 mm | 754 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 166 cm | 176 cm | 185 cm |
| Rider Max Height | 169 cm | 179 cm | 188 cm | 193 cm |
Model Overview
DSX belongs to the Marin Dsx model. Marin launched 15 bikes of this model so far. You can easily view all of the Marin Dsx bikes models from 2024, here.
Model range prices
Marin DSX 2024 is the cheapest bike model and costs 899$. Marin DSX 3 2024 is the most expensive one and costs 1899$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Marin DSX price was 899$. Comparing the average cost of a Gravel bike to this one, you will see that DSX price is 173.86% smaller.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
DSX has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
When leaving the production line, the DSX model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 157 cm – 193 cm (5.15 ft – 6.33 ft). In conclusion, you won’t have a problem finding one that suits you.
