Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Travel Front 60mm -
Fork Suntour GVX
-
Groupset SLX, Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 179cm
LG
176cm - 189cm
XL
187cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 DSX, Supension Adjusted Geometry, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
Suspension Fork
SR Suntour GVX LOR, 60mm Travel, Air Spring, Rebound Adjust, Lockout, Integrated Fender Mounts
Drivetrain
Rear Derailleur
Shimano SLX 12-Speed
Front Derailleur
-
Shift Levers
Shimano Deore 12-Speed
Cassette
Shimano Deore 12-Speed, 10-51T
Crank
Forged Aluminum, 42T Steel Narrow Wide Chainring
Bottom Bracket
Sealed Outboard Bearing
Chain
KMC X12
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum, 100x12mm, Disc, 32H
Rear Hub
Shimano Forged Aluminum, 142x12mm, Microspline, Disc, 32H
Rims
Marin Aluminum Double Wall, 21mm Inner, Disc Specific
Tires
WTB Riddler, 700Cx45mm
Brakes
Brakes
hydraulicDisc
Brake Levers
Shimao Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin MiniRiser
Grips
Marin MTB
Headset
FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
Seat
Saddle
Marin DSX
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.42 mm | 1.44 mm | 1.45 mm |
| Bottom Bracket Height | 277.5 mm | 277.5 mm | 277.5 mm | 277.5 mm |
| Front Center | 653 mm | 685 mm | 711 mm | 737 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 87 mm | 87 mm | 87 mm | 87 mm |
| Stack | 579.2 mm | 597.8 mm | 625.7 mm | 653.6 mm |
| Reach | 396 mm | 421 mm | 436 mm | 451 mm |
| Top Tube Length | 563.23 mm | 593.6 mm | 616.6 mm | 639.6 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 480 mm | 520 mm | 558 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 120 mm | 150 mm | 180 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1061 mm | 1093 mm | 1119 mm | 1145 mm |
| Bottom Bracket Drop | 82 mm | 82 mm | 82 mm | 82 mm |
| Standover Height | 663 mm | 704 mm | 734 mm | 757 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 166 cm | 176 cm | 187 cm |
| Rider Max Height | 169 cm | 179 cm | 189 cm | 193 cm |
Model Overview
DSX FS completes the Marin Dsx model. 15 bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Marin DSX 2022 is the cheapest bike model and costs 979$. Marin DSX FS 2022 is the most expensive one and costs 1699$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Marin released this model in 2022, its price was 1699$. If we compare this with the average Gravel bike cost we notice that the price is 44.91% lower.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
DSX FS components
Fork
Marin DSX FS 2022 bike is equipped with the Suntour GVX fork, and has 60mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The DSX FS 2022 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin DSX FS has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
DSX FS comes in 4 sizes, that range from 160 cm – 193 cm (5.25 ft – 6.33 ft). In conclusion, it won’t take much to find one that’s right for you.
