Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork Suntour GVX
-
Groupset SLX, Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 169cm
MD
166cm - 179cm
LG
176cm - 188cm
XL
185cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 DSX, Supension Adjusted Geometry, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
Suspension Fork
SR/Suntour GVX LOR, 60mm Travel, Air Spring, Rebound Adjust, Lockout, Integrated Fender Mounts
Drivetrain
Rear Derailleur
Shimano SLX 12-Speed
Front Derailleur
-
Shift Levers
Shimano Deore 12-Speed
Cassette
SunRace 12-speed, 11-51
Crank
Forged Aluminum, 42T Steel Narrow Wide Chainring
Bottom Bracket
Sealed Outboard Bearing
Chain
KMC X12
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum, 100x12mm, Disc, 32H
Rear Hub
Forged Aluminum Alloy, 142x12mm, Disc, 32H
Rims
Marin Aluminum Double Wall, 21mm Inner, Disc Specific, Tubeless Compatible
Tires
Vee Tire Co. Rocket Man, 700Cx44mm
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimao Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Mini Riser
Grips
Marin MTB
Headset
FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
Seat
Saddle
Marin DSX
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.42 mm | 1.44 mm | 1.45 mm |
| Bottom Bracket Height | 277.5 mm | 277.5 mm | 277.5 mm | 277.5 mm |
| Front Center | 653 mm | 685 mm | 711 mm | 737 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 87 mm | 87 mm | 87 mm | 87 mm |
| Stack | 579.2 mm | 597.8 mm | 625.7 mm | 653.6 mm |
| Reach | 396 mm | 421 mm | 436 mm | 451 mm |
| Top Tube Length | 563.23 mm | 593.6 mm | 616.6 mm | 639.6 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 480 mm | 520 mm | 558 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 120 mm | 150 mm | 180 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1061 mm | 1093 mm | 1119 mm | 1145 mm |
| Bottom Bracket Drop | 82 mm | 82 mm | 82 mm | 82 mm |
| Standover Height | 663 mm | 704 mm | 734 mm | 757 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 166 cm | 176 cm | 185 cm |
| Rider Max Height | 169 cm | 179 cm | 188 cm | 193 cm |
About this model
DSX FS is part of the Marin Dsx model. There are 15 bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Marin DSX 2023 is the most economical model, with a starting price of 899$. Marin DSX FS 2023 on the other hand costs 1599$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1599$. Comparing the average cost of a Gravel bike to this one, you will see that DSX FS price is 53.97% smaller.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The DSX FS comes factory-installed with the Suntour GVX fork. This has a travel range of 60mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When it comes to wheels, the DSX FS bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin DSX FS has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 157 cm – 193 cm (5.15 ft – 6.33 ft). In conclusion, it won’t take much to find one that’s right for you.
