Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 167cm
MD
164cm - 177cm
LG
174cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, 27.5” Wheels, 68mm BB shell, 135mm Forged Dropouts, Disc Brake
Suspension Fork
SR Suntour XCM HLO Disc, 120mm Travel, Hydraulic Lockout, Preload Adjustment
Drivetrain
Rear Derailleur
Shimano Alivio, 9-Speed, Shadow Design
Front Derailleur
Shimano Altus, Double
Shift Levers
Shimano Altus 2x9
Cassette
Shimano HG200, 9-Speed, 11-36T
Crank
Forged Alloy, Steel Chainrings, 36/22T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X9
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, 6-Bolt Disc, 32H
Rear Hub
Forged Alloy, 6-Bolt Disc, 32H
Rims
Double Wall Alloy
Tires
MTB, 27.5x2.25"
Brakes
Brakes
Hydraulic Disc
Brake Levers
Tektro M275 Hydraulic Disc
Cockpit
Stem
Alloy, 31.8mm, 45mm
Handlebar
31.8 Riser, 20mm Rise, 740mm Width
Grips
Entity MTB, Closed End
Headset
44mm Zero Stack, 8mm Cone
Seat
Saddle
Entity MTB
Seatpost
Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.52 mm | 1.55 mm |
| Bottom Bracket Height | 299 mm | 299 mm | 299 mm |
| Front Center | 646 mm | 661 mm | 681 mm |
| Rake | 46 mm | 46 mm | 46 mm |
| Trail | 91 mm | 91 mm | 105 mm |
| Stack | 616 mm | 616 mm | 656 mm |
| Reach | 389.5 mm | 404.5 mm | 423 mm |
| Top Tube Length | 576 mm | 591 mm | 611 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406 mm | 456 mm | 506 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 100 mm | 105 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1078 mm | 1093 mm | 1113 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm |
| Standover Height | 719 mm | 759 mm | 799 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 157 cm | 164 cm | 174 cm |
| Rider Max Height | 167 cm | 177 cm | 182 cm |
About this model
Eldridge Grade 1 is a Marin Eldridge model. Marin launched 4 bikes of this model so far. Take a sneak peek at all Marin Eldridge bikes models from 2022, by clicking here.
Model range prices
Marin Eldridge Grade 2022 is the most affordable bike of this model and has a price of 499$. On the other hand, Marin Eldridge Grade 1 2022, is the most expensive and costs 549$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 549$. Comparing this to the average Trail bike price, we see that the price is 403.1% lower.
Eldridge Grade 1 components
Fork
Marin Eldridge Grade 1 2022 bike is equipped with the Suntour XCM fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the Eldridge Grade 1 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 157 cm – 182 cm (5.15 ft – 5.97 ft). In short, it won’t be difficult to find the right one for you.
