Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tourney, Shimano -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
147cm - 151cm
SM
148cm - 156cm
MD
153cm - 167cm
LG
164cm - 175cm
XL
185cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Fitness, 6061 Aluminum, 700C Wheels, Disc Brakes, Fender and Rack Mounts
Suspension Fork
Cr-Mo Steel, Straight Blade, Disc Mount, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
Shimano TY510
Shift Levers
Shimano EF41 Shifter/Brake Lever Combo, 3x7-Speed
Cassette
SunRace 7-Speed, 11-34T
Crank
Forged aluminum, 48/38/28T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z50
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, Disc, 32H
Rear Hub
Forged Aluminum Alloy, Disc, 32H
Rims
Marin Aluminum Double Wall, Machined Sidewall
Spokes
14g Stainless Steel
Tires
Marin Fitness 700Cx35
Brakes
Brakes
Tektro Mechanical Disc Brake
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Alloy Threadless
Handlebar
Marin Alloy, 30mm Rise
Grips
Marin Commute
Headset
FSA, Threadless
Seat
Saddle
Marin Fitness Plush
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.47 mm | 1.48 mm | 1.5 mm | 1.52 mm |
| Bottom Bracket Height | 300 mm | 300 mm | 300 mm | 300 mm | 300 mm |
| Front Center | 591 mm | 606 mm | 621 mm | 636 mm | 656 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Stack | 555.89 mm | 574.97 mm | 594.04 mm | 613.11 mm | 641.73 mm |
| Reach | 382.74 mm | 392.09 mm | 401.44 mm | 409.94 mm | 421.19 mm |
| Top Tube Length | 548 mm | 563 mm | 578 mm | 598 mm | 618 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 431.8 mm | 482.6 mm | 520.7 mm | 558.8 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 135 mm | 155 mm | 175 mm | 195 mm | 225 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1012 mm | 1027 mm | 1043 mm | 1057 mm | 1077 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 677 mm | 723 mm | 768 mm | 801 mm | 837 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 147 cm | 148 cm | 153 cm | 164 cm | 185 cm |
| Rider Max Height | 151 cm | 156 cm | 167 cm | 175 cm | 190 cm |
About this model
Fairfax 1 belongs to the Marin Fairfax model. Marin released 57 bikes variations of this model so far. You can easily view all of the Marin Fairfax bikes models from 2020, here.
Model range prices
Marin Fairfax 1 2020 is the most economical model, with a starting price of 429$. Marin Fairfax 4 2020 on the other hand costs 1149$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Fitness bikes average price
If you want to purchase a solid Fitness bike, it is important to know that the average cost is 656$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fitness bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2020 for 429$. Doing a quick comparison, we notice that Fairfax 1 price is 52.91% smaller than the average cost of a Fitness bike.
Overview of components
Fork material
Fairfax 1 has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
The wheels on Fairfax 1 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 147 cm – 190 cm (4.82 ft – 6.23 ft). In conclusion, you won’t have a problem finding one that suits you.
