Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Acera, Tourney -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
149cm - 156cm
SM
153cm - 167cm
MD
164cm - 177cm
LG
174cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 Fitness, Step-Thru Design, 6061 Aluminum, 700C Wheels, Disc Brake, Internal Cable Routing, Fender and Rack Mounts
Suspension Fork
6061 Aluminum, Straight-Blade, Disc Mount, QR Dropouts, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
Shimano Acera, 8-Speed
Front Derailleur
Shimano TY710
Shift Levers
Shimano Altus 2x8
Cassette
SunRace 8-Speed, 11-34T
Crank
Forged Alloy Crank, 46/30T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z8
Pedals
Fitness Platform
Wheels
Front Hub
Forged Aluminum Alloy, Disc, 32H
Rear Hub
Forged Aluminum Alloy, Disc, 32H
Rims
Marin Aluminum Double Wall, Disc Specific
Tires
Vee Tire, Zilent, 700Cx35mm, Puncture Protection, Wire Bead
Brakes
Brakes
Hydraulic Disc
Brake Levers
Tektro Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Alloy Flat
Grips
Marin Ergonomic Locking
Headset
FSA, No.8B
Seat
Saddle
Marin Fitness Plush
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.43 mm | 1.41 mm | 1.39 mm |
| Bottom Bracket Height | 283.5 mm | 283.5 mm | 283.5 mm | 283.5 mm |
| Front Center | 615 mm | 634 mm | 661 mm | 688 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 71 mm | 71 mm | 71 mm |
| Stack | 554 mm | 568.3 mm | 587 mm | 606 mm |
| Reach | 382 mm | 397 mm | 417 mm | 437 mm |
| Top Tube Length | 547 mm | 566.2 mm | 591.8 mm | 617.4 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 520 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 140 mm | 155 mm | 175 mm | 195 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1047 mm | 1067 mm | 1093 mm | 1120 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 533 mm | 564 mm | 604 mm | 625 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 149 cm | 153 cm | 164 cm | 174 cm |
| Rider Max Height | 156 cm | 167 cm | 177 cm | 185 cm |
Model Overview
Fairfax ST 2 belongs to the Marin Fairfax model. Marin launched 57 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Marin Fairfax ST 1 2023 is the most affordable bike of this model and has a price of 499$. On the other hand, Marin Fairfax 3 2023, is the most expensive and costs 989$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Fitness bikes average price
According to our math, the average price for a trustworthy Fitness bike is 656$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fitness bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Marin Fairfax ST 2 price was 699$. If we compare this with the average Fitness bike cost we notice that the price is 6.55% more expensive.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When leaving the production line, the Fairfax ST 2 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Fairfax ST 2 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Fairfax ST 2 comes in 4 sizes, that range from 149 cm – 185 cm (4.89 ft – 6.07 ft). In conclusion, you won’t have a problem finding one that suits you.
