Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Rival 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Columbus Thron Butted and Formed CrMo, 700c Wheels, Full Rack and Fender Mounts, 142x12mm Naild Locking Thru-Axle Dropouts, Disc
Suspension Fork
Butted CrMo, Fender and Rack Eyelets, 15mm Thru-axle, Post-Mount Disc
Drivetrain
Rear Derailleur
SRAM Rival 1
Shift Levers
SRAM Rival 1x11-Speed
Cassette
SRAM XG-1150 11-Speed, 10-42T
Crank
Forged Alloy 1x11, Hollow CrMo Spindle, Narrow-Wide 40T
Bottom Bracket
External Sealed Cartridge Bearing
Chain
KMC X11
Pedals
Aluminum Platform
Wheels
Front Hub
Formula, 100x15mm, 6-Bolt Disc, 32H
Rear Hub
Formula, 142x12mm, Alloy Axle, Quad Cartridge Sealed Bearing, SRAM XD Driver, 6-Bolt Disc, 32H
Rims
WTB KOM i21, 21mm Inner, Tubeless Ready
Tires
Schwalbe G-ONE Evo, 700x40C, Kevlar Puncture Protection, Folding, Tubeless Ready
Brakes
Brakes
SRAM Rival Hydraulic Disc, 160mm Rotor
Brake Levers
SRAM Rival 22 DoubleTap Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Four Corners Flared Drop
Grips
Marin Silicon Gel Tape
Headset
FSA Orbit CE, Sealed Cartridge Bearing
Seat
Saddle
WTB Volt Race
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.5 mm | 1.52 mm | 1.55 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm |
| Front Center | 610 mm | 625 mm | 644 mm | 658 mm |
| Rake | 49 mm | 49 mm | 49 mm | 49 mm |
| Trail | 59 mm | 58 mm | 58 mm | 59 mm |
| Stack | 584 mm | 607 mm | 631 mm | 655 mm |
| Reach | 397 mm | 404 mm | 416 mm | 422 mm |
| Top Tube Length | 562 mm | 582 mm | 607 mm | 632 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 72 ° |
| Seat Tube Length | 475 mm | 495 mm | 525 mm | 550 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 150 mm | 175 mm | 200 mm | 225 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1057 mm | 1072 mm | 1092 mm | 1105 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 742 mm | 763 mm | 791 mm | 815 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Four Corners Elite completes the Marin Four model. Marin launched 13 bikes of this model so far. You can easily view all of the Marin Four bikes models from 2016, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Touring bikes average price
If you want to purchase a solid Touring bike, it is important to know that the average cost is 1007$. However, this doesn’t mean that if you spend less money on a Touring bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Four Corners Elite components
Fork material
The fork on this bike is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
The wheels on Four Corners Elite are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Four Corners Elite is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
