Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b / 700c -
Groupset Apex 1, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 Double Butted and Formed CrMo, Size-Specific Wheels (XS, S = 650B, M, L, XL = 700C), Utilitour Biometric Geometry, Fender and Rack Mounts, 142x12mm Thru-Axle Dropouts, Chainstay Disc Mount
Suspension Fork
Butted CrMo, Fender, Rack and Bottle Cage Eyelets, 15mm Thru-Axle, Post-Mount Disc
Drivetrain
Rear Derailleur
SRAM Apex 1 11-Speed
Front Derailleur
-
Shift Levers
SRAM Apex 1 1x11 Speed
Cassette
e*thirteen TRS 11-Speed, 9-44T
Crank
FSA Gossamer Pro, Megatooth 38T Chainring, BB386EVO Alloy Spindle
Bottom Bracket
FSA MegaExo Threaded
Chain
KMC X11
Pedals
Trekking Platform
Wheels
Front Hub
Forged Aluminum Alloy, 100x15mm, 6-Bolt Disc, 32H
Rear Hub
Forged Aluminum Alloy, 142x12mm, Alloy Axle, Quad Cartridge Sealed Bearings, SRAM XD Driver, 6-Bolt Disc, 32H
Rims
WTB KOM i25, 25mm Inner, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
WTB Resolute, 650B/700Cx42, Folding Bead, Tubeless Compatible
Brakes
Brakes
SRAM Apex 1 Hydraulic Disc, 160mm Rotor
Brake Levers
SRAM Apex 1 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 12º Flared Drop
Grips
Marin Silicone Gel Tape
Headset
FSA Orbit CE, Sealed Cartridge Bearings
Seat
Saddle
WTB Volt Race 142 Custom
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.53 mm | 1.53 mm | 1.57 mm | 1.59 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm | 285 mm | 285 mm |
| Front Center | 604 mm | 615 mm | 641 mm | 660 mm | 685 mm |
| Rake | 43 mm | 43 mm | 49 mm | 49 mm | 49 mm |
| Trail | 67 mm | 67 mm | 61 mm | 62 mm | 61 mm |
| Stack | 558 mm | 578 mm | 615 mm | 644.3 mm | 675.6 mm |
| Reach | 374.7 mm | 379 mm | 401.3 mm | 410.6 mm | 424.6 mm |
| Top Tube Length | 530 mm | 550.8 mm | 584.1 mm | 614.4 mm | 644.8 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73.5 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 381 mm | 422 mm | 462 mm | 495 mm | 528 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 177 mm | 198 mm | 198 mm | 229 mm | 262 mm |
| Chainstay Length | 430 mm | 430 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1028 mm | 1039 mm | 1079 mm | 1098 mm | 1123 mm |
| Bottom Bracket Drop | 53 mm | 53 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 664 mm | 704 mm | 742 mm | 775 mm | 807 mm |
| Wheels | 650 | 650 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Four Corners Elite completes the Marin Four model. 13 bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Marin Four Corners 2018 is the cheapest bike model and costs 1099$. Marin Four Corners Elite 2018 is the most expensive one and costs 1999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Touring bikes average price
According to our math, the average price for a trustworthy Touring bike is 1007$. However, you could also get a good Touring bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2018 for 1999$. If we compare this with the average Touring bike cost we notice that the price is 98.51% higher.
Four Corners Elite components
Fork material
Four Corners Elite has a steel fork, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
When it comes to wheels, the Four Corners Elite bike is equipped with the aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Four Corners Elite comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
