Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b / 700c -
Groupset Apex 1, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 Double Butted and Formed CrMo,Size-Specific Wheels (XS, S = 650B, M, L, XL =700C), Utilitour Biometric Geometry, Fender and Rack Mounts, 142x12mm Thru-Axle Dropouts, Chainstay Disc Mount
Suspension Fork
Butted CrMo, Fender, Rack and Bottle Cage Eyelets, 15mm Thru-Axle, Post-Mount Disc
Drivetrain
Rear Derailleur
SRAM Apex 1 11-Speed
Front Derailleur
---
Shift Levers
SRAM Apex 1 1x11 Speed
Cassette
e*thirteen TRS 11-Speed, 9-44T
Crank
FSA Gossamer Pro, Megatooth 38T Chainring, BB386EVO Alloy Spindle
Bottom Bracket
BB86/BB92, press-fit
Chain
KMCX11
Pedals
Trekking Platform
Wheels
Front Hub
Forged Aluminum Alloy, 100x15mm, 6-Bolt Disc, 32H
Rear Hub
Forged Aluminum Alloy, 142x12mm, Alloy Axle, Quad Cartridge Sealed Bearings, SRAM XD Driver, 6-Bolt Disc, 32H
Rims
WTB KOM i25, 25mm Inner, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
WTB Resolute, 650B/700Cx42, Folding Bead, Tubeless Compatible
Brakes
Brakes
SRAM Apex 1 Hydraulic Disc, 160mm Rotor
Brake Levers
SRAM Apex 1 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 12º Flared Drop
Grips
Marin Silicone Gel Tape
Headset
FSA No.8D, Sealed Cartridge Bearings
Seat
Saddle
WTB Volt Sport 142 Custom
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.53 mm | 1.53 mm | 1.57 mm | 1.59 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm | 285 mm | 285 mm |
| Front Center | 604 mm | 615 mm | 641 mm | 660 mm | 685 mm |
| Rake | 43 mm | 43 mm | 49 mm | 49 mm | 49 mm |
| Trail | 67 mm | 67 mm | 61 mm | 62 mm | 61 mm |
| Stack | 558 mm | 578 mm | 615 mm | 644.3 mm | 675.6 mm |
| Reach | 374.7 mm | 379 mm | 401.3 mm | 410.6 mm | 424.6 mm |
| Top Tube Length | 530 mm | 550.8 mm | 584.1 mm | 614.4 mm | 644.8 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73.5 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 381 mm | 422 mm | 462 mm | 495 mm | 528 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 177 mm | 198 mm | 198 mm | 229 mm | 262 mm |
| Chainstay Length | 430 mm | 430 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1028 mm | 1039 mm | 1079 mm | 1098 mm | 1123 mm |
| Bottom Bracket Drop | 53 mm | 53 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 664 mm | 704 mm | 742 mm | 775 mm | 807 mm |
| Wheels | 650 | 650 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Four Corners Elite completes the Marin Four model. Marin released 13 bikes variations of this model so far. Take a sneak peek at all Marin Four bikes models from 2019, by clicking here.
Model range prices
The most economical model, the Marin Four Corners 2019 has a starting price of 1039$. Marin Four Corners Elite 2019 on the other hand is the most expensive at 2649$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Touring bikes average price
According to our calculations, the average cost of a Touring bike that is reliable is 1007$. However, this doesn’t mean that if you spend less money on a Touring bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2019 and its price was 2649$. In conclusion, this bike price is 163.06% higher than the price of the average Touring bike.
Four Corners Elite components
Fork material
Four Corners Elite has a steel fork, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
The Four Corners Elite 2019 bike is equipped with aluminum wheels when leaving the factory. After 700c wheels, 650b is the second most popular choice for road bikes. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
