Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset X7, Apex -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum, 700c Wheels, Relieved Head Tube and BB, Internal Cable Routing, Post Mount Disc Specific Forged Dropouts
Suspension Fork
Carbon w/ Alloy Steerer, Post-Mount Disc
Drivetrain
Rear Derailleur
SRAM X7 Type 2.1 w/Clutch
Shift Levers
SRAM Apex 1x10-Speed
Cassette
Sunrace 10-Speed, 11-42T
Crank
Forged Alloy 1x10, Hollow CrMo Spindle, Narrow-Wide 42T
Bottom Bracket
External Sealed Cartridge Bearing
Chain
KMC X10
Pedals
Resin Platform
Wheels
Front Hub
Formula, 6-Bolt Disc, 32H
Rear Hub
Formula, 6-Bolt Disc, 32H
Rims
Maddux FR240, Double Wall, Disc Specific, 19mm Inner
Tires
Schwalbe G-ONE Performance, 700x30C, Kevlar Puncture Protection, Folding
Brakes
Brakes
Tektro Spyre-C Road Mechanical Disc, 160mm Rotor
Brake Levers
SRAM Apex DoubleTap
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Compact 12º Flared Drop, Flat Top
Grips
Marin Shock Absorbing Microfiber Tape
Headset
FSA No.8B
Seat
Saddle
Marin Endurance Concept
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.6 mm | 1.58 mm | 1.55 mm | 1.57 mm | 1.56 mm | 1.59 mm |
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 550 mm | 567 mm | 588 mm | 600 mm | 620 mm | 629 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 62 mm | 60 mm | 60 mm | 59 mm | 59 mm | 59 mm |
| Stack | 551.8 mm | 567 mm | 581.2 mm | 601.2 mm | 620.3 mm | 639.4 mm |
| Reach | 344.4 mm | 359.7 mm | 375.4 mm | 383.8 mm | 398 mm | 401 mm |
| Top Tube Length | 502 mm | 527 mm | 547 mm | 567 mm | 587 mm | 602 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 72 ° | 72.25 ° | 72.25 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 955 mm | 973 mm | 993 mm | 1006 mm | 1026 mm | 1035 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 762 mm | 778 mm | 795 mm | 814 mm | 833 mm | 851 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Gestalt 2 is part of the Marin Gestalt model. There are 42 bikes that carry this model name. You can easily view all of the Marin Gestalt bikes models from 2016, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Gestalt 2 components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
As for the wheels, Marin Gestalt 2 2016, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Gestalt 2 comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
