Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GX, Apex -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum, 700C Wheels, Relieved Head Tube and BB, Internal Cable Routing, Post Mount Disc Specific Forged Dropouts
Suspension Fork
Carbon w/ Alloy Steerer, Post-Mount Disc
Drivetrain
Rear Derailleur
SRAM GX 10-Speed
Front Derailleur
-
Shift Levers
SRAM Apex 1x10-Speed
Cassette
Sunrace 10-Speed, 11-42T
Crank
Forged Alloy 1x10, Hollow CrMo Spindle, Narrow-Wide 42T
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X10
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rear Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rims
Marin Aluminum Double Wall, 19mm Inner, 24mm Tall, Disc Specific, Tubeless Compatible
Tires
Schwalbe G-ONE Performance, 700Cx30, Folding Bead, Kevlar Puncture Protectio
Brakes
Brakes
Tektro Spyre-C Road Mechanical Disc, 160mm Rotor
Brake Levers
SRAM Apex DoubleTap
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Compact 12º Flared Drop, Flat Top
Grips
Marin Shock Absorbing Microfiber Tape
Headset
FSA No.8B
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.6 mm | 1.58 mm | 1.55 mm | 1.57 mm | 1.56 mm | 1.59 mm |
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 550 mm | 567 mm | 588 mm | 600 mm | 620 mm | 629 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 62 mm | 60 mm | 60 mm | 59 mm | 59 mm | 59 mm |
| Stack | 551.8 mm | 567 mm | 581.2 mm | 601.2 mm | 620.3 mm | 639.4 mm |
| Reach | 344.4 mm | 359.7 mm | 375.4 mm | 383.8 mm | 398 mm | 401 mm |
| Top Tube Length | 502 mm | 527 mm | 547 mm | 567 mm | 587 mm | 602 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 72 ° | 72.25 ° | 72.25 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 955 mm | 973 mm | 993 mm | 1006 mm | 1026 mm | 1035 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 762 mm | 778 mm | 795 mm | 814 mm | 833 mm | 851 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Gestalt 2 completes the Marin Gestalt model. There are 42 bikes that carry this model name. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Gestalt 2 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
As for the wheels, Marin Gestalt 2 2017, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Gestalt 2 is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
