Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris, FSA -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 Beyond Road, 6061 Aluminum, 700C Wheels, Relieved Head Tube and BB, Internal Cable Routing, Disc Specific Forged Dropouts w/ Mudguard and Rack Mounts
Suspension Fork
6061 Aluminum, Straight-Blade, Post-Mount Disc
Drivetrain
Rear Derailleur
Shimano Claris 8-Speed
Front Derailleur
Shimano Claris
Shift Levers
Shimano Claris 2x8-Speed
Cassette
SunRace 8-Speed, 11-32T
Crank
FSA Tempo Compact, 50/34T
Bottom Bracket
Sealed Bearing Square Taper
Chain
KMC Z8
Pedals
Marin Oso OEM Nylon Platform
Wheels
Front Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rear Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rims
Marin Aluminum Double Wall, 19mm Inner, 25mm Tall, Disc Specific
Tires
Vee Tire Co. Zilent, 700x35
Brakes
Brakes
Mechanical Disc
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 12º Flared Drop
Grips
Marin Perforated Tape
Headset
FSA No.8B
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.54 mm | 1.56 mm | 1.56 mm | 1.55 mm | 1.6 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 588 mm | 594 mm | 604 mm | 620 mm | 640 mm | 650 |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 67 mm | 64 mm | 63 mm | 64 mm | 65 mm | 64 mm |
| Stack | 544 mm | 560 mm | 574 mm | 593 mm | 612 mm | 633 mm |
| Reach | 359 mm | 364 mm | 369 mm | 379 mm | 394 mm | 396 mm |
| Top Tube Length | 512 mm | 527 mm | 542 mm | 557 mm | 577 mm | 592 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 460 mm | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1000 mm | 1006 mm | 1016 mm | 1032 mm | 1052 mm | 1062 mm |
| Bottom Bracket Drop | 78 mm | 78 mm | 78 mm | 78 mm | 78 mm | 78 mm |
| Standover Height | 706 mm | 724 mm | 747 mm | 767 mm | 786 mm | 806 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Gestalt is a Marin Gestalt model. Marin released 42 bikes variations of this model so far. Check out the entire range from 2024 of this model, by clicking this link.
Model range prices
Marin Gestalt 2024 is the cheapest bike model and costs 999$. Marin Gestalt 2 2024 is the most expensive one and costs 1599$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Marin Gestalt price was 999$. Comparing the average cost of a Gravel bike to this one, you will see that Gestalt price is 146.45% smaller.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
The Gestalt 2024 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Gestalt comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
