Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 600, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
Suspension Fork
Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Drivetrain
Rear Derailleur
Shimano GRX Shadow w/ Clutch
Front Derailleur
-
Shift Levers
Shimano GRX GX8010, 1x11-Speed, Integrated Dropper Lever
Cassette
Shimano 11-Speed, 11-42T
Crank
FSA Gossamer Pro, Megatooth 42T Chainring, BB386EVO Alloy Spindle
Bottom Bracket
FSA MegaExo Threaded
Chain
KMC X11
Pedals
-
Wheels
Front Hub
Forged Aluminum Alloy, 100x12mm, 32H
Rear Hub
Forged Aluminum Alloy, 142x12mm, 32H
Rims
Marin Aluminum Double Wall, 21mm Inner, 30mm Tall, Disc Specific, Tubeless Compatible
Tires
Schwalbe G-One Performance, 700Cx40mm, Folding Bead
Brakes
Brake Levers
Shimano GRX Hydraulic w/ Shifter and Integrated Dropper Lever
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 16º Flared Drop
Grips
Marin Shock Absorbing Perforated Tape
Headset
FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
Seat
Saddle
Marin Beyond Road Concept Elite
Seatpost
TranzX YSP38J Dropper Post, 105mm/85mm Travel, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.51 mm | 1.55 mm | 1.55 mm | 1.54 mm | 1.56 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 597 mm | 598 mm | 604 mm | 619 mm | 634 mm | 644 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 67 mm | 67 mm | 64 mm | 70 mm | 67 mm |
| Stack | 547.6 mm | 563.7 mm | 577.8 mm | 598.7 mm | 617.7 mm | 638.4 mm |
| Reach | 372 mm | 372.1 mm | 372.5 mm | 386.3 mm | 400.8 mm | 409.6 mm |
| Top Tube Length | 519 mm | 534 mm | 544 mm | 564 mm | 584 mm | 599 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 450 mm | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 998 mm | 999 mm | 1004 mm | 1020 mm | 1035 mm | 1045 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 582 mm | 665 mm | 693 mm | 713 mm | 726 mm | 746 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Gestalt X11 is part of the Marin Gestalt model. Marin released 42 bikes variations of this model so far. You can easily view all of the Marin Gestalt bikes models from 2021, here.
Model range prices
Marin Gestalt 2021 is the most economical model, with a starting price of 979$. Marin Gestalt X11 2021 on the other hand costs 2369$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2021 and its price was 2369$. If we compare this with the average Gravel bike cost we notice that the price is 3.93% lower.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Marin Gestalt X11 2021, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Gestalt X11 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
