Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum Frame, 27.5” Wheels, 120mm Travel, MultiTrac Suspension Platform, 135mm Open Dropout (Upgradable to 142x12mm Thru-Axle)
Suspension Fork
RockShox Recon Silver RL 27.5", 120mm Travel, Compression and Rebound Adjustment, Alloy Tapered Steerer, 100x15mm Thru-Axle, 42mm Offset
Rear Shock
X-Fusion O2 Pro R, 190x51mm, Custom Tune, 22.2mm x M8 Hardware
Drivetrain
Rear Derailleur
Shimano Deore Shadow Plus Direct Mount 10-Speed
Front Derailleur
- - -
Shift Levers
Shimano Deore 1x10-Speed
Cassette
SunRace 10-Speed, 11-42T
Crank
Marin Forged Alloy 1x10, Hollow Spindle, Steel Narrow-Wide 32T Chainring, 76mm BCD
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X10
Chain Guide
No
Pedals
- - -
Wheels
Front Hub
Formula, 100x15mm, Centerlock Disc, 32H
Rear Hub
Joytech, 135mm, Quad Sealed Bearings, Centerlock Disc, 32H
Rims
Marin, Double Wall Alloy, 27mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
Schwalbe Hans Dampf, Performance Line, 27.5"x2.35"
Brakes
Brakes
Shimano BR-M315 Hydraulic Disc, 180mm Rotor
Brake Levers
Shimano BL-M315 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 45mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 15mm Rise, 780mm Width, 4º Up, 9º Back
Grips
Marin Dual Density
Headset
FSA No 57E, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
Marin, Two Bolt Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.38 mm | 1.33 mm | 1.3 mm | 1.27 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm | 337 mm |
| Front Center | 678 mm | 699 mm | 719 mm | 735 mm | 750 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | -609 mm | -708 mm | -814 mm | -931 mm | -1066 mm |
| Stack | 577 mm | 581.6 mm | 586.2 mm | 590.8 mm | 595.4 mm |
| Reach | 403 mm | 421 mm | 440.2 mm | 453.9 mm | 467.5 mm |
| Top Tube Length | 565.9 mm | 589.7 mm | 613 mm | 633 mm | 643 mm |
| Seat Tube Angle | 74.2 ° | 73.8 ° | 73.5 ° | 73.2 ° | 73 ° |
| Seat Tube Length | 335 mm | 385 mm | 435 mm | 485 mm | 535 mm |
| Head Tube Length | 110 mm | 115 mm | 120 mm | 125 mm | 130 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1110 mm | 1131 mm | 1151 mm | 1167 mm | 1182 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm | 18 mm | 18 mm |
| Standover Height | 649 mm | 671 mm | 700 | 744 mm | 786 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Hawk Hill belongs to the Marin Hawk model. There are 13 bikes that carry this model name. You can easily view all of the Marin Hawk bikes models from 2018, here.
Model range prices
Marin Hawk Hill 2018 is the most affordable bike of this model and has a price of 1499$. On the other hand, Marin Hawk Hill 3 2018, is the most expensive and costs 2649$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Marin released this model in 2018, its price was 1499$. Comparing the average cost of a Trail bike to this one, you will see that Hawk Hill price is 84.26% lower.
Overview of components
Fork
Marin Hawk Hill 2018 bike is equipped with the RockShox Recon Silver RL fork, and has 120mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
Hawk Hill has an aluminum fork, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Rear Shock
The Hawk Hill has a rear shock with a travel of 120mm. The model X-Fusion O2 Pro R is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The wheels on Hawk Hill are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Marin Hawk Hill bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
