Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 120mm -
Travel Rear 120mm -
Fork X Fusion
-
Groupset Deore, microSHIFT -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum Frame, 24" wheel with clearance for up to 26", 120mm Travel, MultiTrac Suspension Platform, 135mm Open Dropout (Upgradeable to 142x12mm Thru-Axle), 73mm Threaded BB
Suspension Fork
X-Fusion Velvet RLC 26", 120mm Travel, Compression and Rebound Adjustment, 100x15mm Thru-Axle
Drivetrain
Rear Derailleur
Shimano Deore Shadow Plus
Front Derailleur
-
Shift Levers
Micro Shift, SLM895, 11 speed
Cassette
SunRace 11-Speed, 11-46T
Crank
Marin Forged Alloy 1x11, Hollow Spindle, Steel Narrow-Wide 32T Chainring, Direct Mount Type
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X11
Pedals
Kids Specific Nylon Pedal
Wheels
Front Hub
Forged Alloy, 100x15mm, Centerlock Disc, 32H
Rear Hub
Forged Alloy, 135mm, Quad Sealed Bearings, Centerlock Disc, 32H
Rims
Marin, Double Wall Alloy, 27mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Spokes
14g Stainless Steel
Tires
Vee Tire Co, Flow Snap 24x2.4", Tackee Compound, Wire Bead
Brakes
Brakes
Shimano MT-201 Hydraulic Disc, 180mm Rotor
Brake Levers
Shimano BL-MT201 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 15mm Rise, 720mm Width, 4º Up, 9º Back
Grips
Marin Dual Density
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
Marin Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13" |
|---|---|
| Stack Reach Ratio | 1.41 mm |
| Bottom Bracket Height | 305 mm |
| Front Center | 590 mm |
| Rake | 42 mm |
| Stack | 539.24 mm |
| Reach | 383 mm |
| Top Tube Length | 539 mm |
| Seat Tube Angle | 69 ° |
| Seat Tube Length | 335 mm |
| Head Tube Angle | 67.5 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 431 mm |
| Wheelbase | 1021 mm |
| Bottom Bracket Drop | 10 mm |
| Standover Height | 624 mm |
| Wheels | 24" |
Model Overview
Hawk Hill Jr completes the Marin Hawk model. Marin launched 13 bikes of this model so far. Take a sneak peek at all Marin Hawk bikes models from 2020, by clicking here.
Model range prices
Marin Hawk Hill Jr 2020 is the cheapest bike model and costs 1599$. Marin Hawk Hill 3 2020 is the most expensive one and costs 2649$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Youth bikes
If you want an acceptable Youth bike you should know that the average price is 278$. However, this doesn’t mean that if you spend less money on a Youth bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Marin released this model in 2020, its price was 1599$. Doing a quick comparison, we notice that Hawk Hill Jr price is 475.18% higher than the average cost of a Youth bike.
Hawk Hill Jr components
Fork
The Hawk Hill Jr comes factory-installed with the X Fusion fork. This has a travel range of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on Hawk Hill Jr are the 24″ aluminum type. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Hawk Hill Jr comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
